82.5mm Unilin Thin-R XT/TL-MF Insulated Drylining Board

Unilin Insulation | The new name for Xtratherm Insulation in the UK & Ireland.

The 82.5mm XT/TL-MF Thin-R Thermal Liner (Mechanically Fixed) features a Unilin 70mm PIR insulation layer bonded to 12.5mm tapered edge plasterboard with composite foil facing. This insulated composite panel delivers both thermal performance and drylining capabilities for internal walls, sloped roofs, and ceilings in mechanically fixed applications.

The composite foil facing on both sides incorporates an integral vapour control layer that minimises condensation risk. Engineered to combine high thermal insulation and drylining in a single installation, this product offers an efficient solution for new builds and renovation work.

Properties

Brand: Unilin

Thickness: 82.5mm overall

Model: 82.5mm XT/TL-MF Drylined

Dimensions: 2,400mm x 1,200mm x 82.5mm

Compressive Strength: 150 kPa

Density: 30-32 Kg/m3

Length: 2400mm

Material: PIR core ǀ Gypsum plasterboard

Profile: Tapered edge plasterboard

R-Value: 3.24 m2K/W

Thermal Conductivity: 0.022 W/mk

Vapour Resistivity: 100 MNs/gm

Finish: Foil facing on both sides ǀ Composite Kraft facings

Reaction To Fire: Euroclass B s1 d0

Applications: internal walls, sloped roofs & ceilings - Mechanically Fixed Applications

Vapour Control Layer: Yes, build in

Fixing method: Mechanically Fixed

Features: PIR Thermal Insulated Plasterboard

Type: Thermal Liner®

Flexural Strength: ≥160N Transverse / ≥400N Longitudinal

Benefits

1. Combined insulation and drylining in one step
2. Integrated vapour control layer for condensation prevention
3. Thinner profile without compromising performance
4. Suitable for diverse wall insulation applications

About

The 82.5mm Thermal Liner XT/TL-MF delivers comprehensive thermal insulation and drylining performance in a single application, making it the ideal choice for new construction and refurbishment schemes. This product enhances your home's energy efficiency whilst reducing heating costs and creating more comfortable living spaces.

The insulation board is chemically stable and manufactured with a blowing agent featuring zero Ozone Depletion Potential (ODP) and minimal Global Warming Potential (GWP).

Upgrading your home's thermal performance delivers substantial advantages, including lower energy bills and enhanced comfort levels. The Unilin XT/TL-MF Thermal Liner represents an effective investment in energy efficiency and sustainable building practice.

The PIR board provides fire resistance through continuous adhesive ribbons, particularly around vulnerable areas such as window and door openings.

What are Insulated Plasterboards?

The 82.5mm XT/TL-MF insulated plasterboards (70mm insulation + 12.5mm plasterboard) combine plasterboard with an integrated insulation layer, typically PIR-based. The insulation is bonded to the plasterboard to form a single, multi-purpose panel offering both thermal performance and a finished surface. These panels improve thermal and sound insulation whilst streamlining installation. Commonly used in walls, ceilings, and floors, they are available in various sizes and thicknesses to meet specific building needs.
