Kingspan Thermaroof TR26 90mm Flat Roof Board

Discover the Kingspan Thermaroof TR26, a high-performance PIR insulation board engineered for flat roof applications. This product delivers exceptional thermal performance and integrates seamlessly with mechanically-fixed, single-ply waterproofing systems and green roof installations. Suitable for both new construction and refurbishment work, the 90mm TR26 offers straightforward installation and rapid deployment for accelerated building schedules.

Product Specification

Brand: Kingspan®

Model: 90mm TR26 Thermaroof

Thickness: 90mm

Length: 2400mm

Width: 1200mm

Weight: 25.23kg

Board Coverage: 2.88m2

Pack Coverage: 8.64m2

Pack Quantity: 3 sheets

R-Value: 4.05 m2K/W

Thermal Conductivity: 0.022 W/mK

Dimensions: 2,400mm x 1,200mm x 90mm

Colour: Light Yellow | Silver

Compressive Strength: 150kPa

Vapour resistivity: 100

Density: 32kg/m3

Material: PIR Insulation Polyisocyanurate (rigid polyurethane foam PU)

Profile: Square edge

Finish: Low emissivity composite foil facings

Applications: Used for flat roofs waterproofed with mechanically fixed single-ply waterproofing.

BBA Certified: Yes

Features: Fully compatible with flat roof waterproofing and green roof systems

Key Features:

1. Superior thermal performance: The 90mm Thermaroof TR26 delivers outstanding thermal efficiency for flat roof applications, maximising energy conservation.
2. Mechanically-fixed single-ply compatibility: This board works effectively with the majority of mechanically-fixed, single-ply waterproofing systems, providing flexibility across diverse roofing projects.
3. FM Approval to FM 4470: Certified to FM 4470 standards, ensuring compliance with recognised industry quality benchmarks.
4. Straightforward installation: The board's design facilitates quick and efficient handling, streamlining the installation process on site.
5. Versatile application: Performs reliably in both new-build and refurbishment scenarios, adapting to various project requirements.
6. Tapered system availability: Available as a tapered insulation system to establish roof slope and promote effective drainage and water management.

Roof Waterproofing

The Kingspan Thermaroof TR26 is compatible with most mechanically fixed single–ply waterproofing membranes.

Water Vapour Control

Installation Guidelines: New Build Roofs: For new build applications, a separate vapour control layer is recommended unless the board is installed over a sealed metal deck. A condensation risk analysis should be completed for each project to confirm appropriate installation methods.

Refurbishment Projects with Existing Insulated Flat Roofs or Insulated Steel Faced Composite Panels: When upgrading existing insulated flat roofs or steel-faced composite panel roofs, conduct a U-value calculation and condensation risk assessment. These evaluations determine the correct insulation thickness to achieve required thermal performance whilst preventing interstitial condensation.

Installation over Existing Bituminous Waterproofing Roof Membrane: Where TR26 is installed over an existing bituminous waterproofing membrane in good condition, the membrane can function as a vapour control layer. If the membrane is compromised, install a separate vapour control layer.

Minimum Requirements for Separate Vapour Control Layer: A separate vapour control layer should comprise a 1000 gauge (250 micron) polythene sheet. All joints must be lapped and sealed with double-sided self-adhesive tape for optimal performance.
