65mm EcoTherm Eco-Versal PIR Insulation Board

The 65mm EcoTherm Eco-Versal PIR delivers a comprehensive 5-in-1 solution with a rigid polyisocyanurate (PIR) core and dual aluminium foil composite facing, offering no fibre construction.

This 65mm PIR Insulation Board suits both new builds and thermal upgrades to existing structures, providing an economical approach to lowering CO2 footprints and meeting Building Regulations/Standards. The universal design of 65mm Ecotherm makes it suitable for insulating pitched roofs, floors, walls, dormer cheeks, and ceilings.

Properties

Manufacturer: EcoTherm®

Thickness: 65mm Insulation Board

Weight: 6.96kg

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 65mm

Material: Polyisocyanurate (PIR)

R-Value: 2.95 m2K/W

Thermal Conductivity: 0.022 W/mk

Vapour Resistivity: 100 MNs/gm

Finish: Aluminium composite foil

Fire Rate: Euroclass F

Core: Fibre free rigid polyisocyanurate (PIR) insulant manufactured with a blowing agent that is CFC/HCFC free and has zero Ozone Depletion Potential (ODP) with a low Global Warming Potential (GWP)

Compressive Strength: 140 kPa when tested at 10% compression to BS EN 826: 2013

Applications: Roofs ǀ Walls ǀ Floors ǀ Ceilings

Features: General Purpose PIR Insulation Board

Applications

This 65mm ecotherm eco versal product works well for both new construction and thermal enhancement of existing building components. Its versatility extends to numerous applications:

1. Floors
2. Pitched roofs
3. Cold flat roofs
4. Timber frame walls
5. Solid walls
6. Dormer cheeks
7. Ceilings
8. Room-in-the-roof applications

For floors | Moisture tolerance guidelines for Eco-Versal are as follows:

- The 65mm ecotherm floor insulation must be positioned above the Damp Proof Membrane (DPM) and should not be exposed to ground moisture contact.

- Where a concrete slab is present or specified, lay a protective membrane with minimum 500 gauge thickness over Eco-Versal before applying the screed.

- Our 65mm Ecotherm PIR insulation works with most Underfloor Heating Systems (UFH). A minimum 500 gauge polythene sheet must be placed over the 55mm Insulation Boards before UFH installation. Refer to your UFH system manufacturer's guidance during installation.

For Walls | The guidelines for breathable membrane and vapour control when using 65mm ecotherm Wall insulation are as follows:

- Secure a breathable membrane in accordance with manufacturer specifications.

- Install a Vapour Control Layer (VCL) behind the plasterboard to reduce condensation risk. This may be unnecessary if using insulated plasterboard.

For Roofs | Guidelines for using breathable membrane, vapour control, vertical battens, and insulation layers with Eco-Versal are as follows:

- Fix a Breathable Membrane per manufacturer instructions. For pitched roofs, lay the membrane over rafters and secure using tile or slate laths.

- Assess the requirement for a Vapour Control Layer (VCL) and/or undertile ventilation according to BS 5250:2021 (Code of practice for control of condensation in buildings).

- For all over-rafter installations, secure 65mm ecotherm Roof Insulation using vertical counter battens, enabling traditional slate and tile lath fixing methods.

- Lay the breathable membrane directly on the 65mm Eco-Versal board before installing counter battens. Alternatively, install counter battens on top of the 65mm PIR Board and drape the breathable membrane over them.

- For applications requiring low U-values, consider installing insulation between rafters and using Insulated Plasterboard such as Ecotherm Eco-Liner on the rafter underside for improved performance.
