130mm Unilin FR/ALU Flat Roof Insulation Board

130mm Unilin FR/ALU, previously known as 130mm Xtratherm FR/ALU, delivers premium Polyisocyanurate flat roof insulation with vapor-tight aluminium foil facings for compatibility with single-ply membranes. Part of Unilin's comprehensive range of high-performance flat roof boards, it provides complete solutions for flat roof applications.

Product specification

Brand: Unilin Insulation FR/ALU (formerly Xtratherm FR/ALU)

Model: 130mm Unilin FR/ALU

Thickness: 130mm

Thickness: 25mm, 30mm, 40mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 125mm, 130mm, 140mm, 150mm

Length: 2400mm

Width: 1200mm

Board Coverage: 2.88m2

Pack Coverage: 8.64m2

Pack Quantity: 3 sheets

Pack Weight: 36 kg

Dimensions: 2,400mm x 1,200mm x 130mm

Thermal Conductivity: 0.022 W/mK

R-Value: 5.91 m2K/W

Colour: Light yellow

Density: 32 Kg/m3

Compressive Strength: > 150kPa

Material: Polyisocyanurate Rigid Foam ( PIR insulation board )

Profile: Square Edge

Fire Reaction: Euroclass B, s2-d0

Finish: Vapour resistant gas-tight foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Applications: Flat Roof Waterproofing Systems

BBA Certified: Yes (No. 11/4817)

Fixing method: Mechanically fixed single ply waterproofing systems

Foil faced: Yes, gas-tight foil facings on both sides

Features: Composite gas-tight foil facings on both sides

Manufacturer: Unilin Insulation®

Main Highlights:

1. Exceptional Thermal Efficiency
2. Foil facers providing effective vapor resistance
3. Suitable for mechanically fixed single-ply systems
4. This product has an Environmental Product Declaration (EPD) certified by IGBC. For additional information, please reach out to our technical support.

Advantages:

1. Exceptional Thermal Efficiency
2. Compatibility with mechanically fixed single-ply systems and loose-laid ballasted systems
3. Effective vapor resistance with foil facers
4. The product comes with an Environmental Product Declaration (EPD) certified by IGBC. For more information, please contact our technical support team.

About

The 130mm Unilin FR/ALU Flat Roof Insulation Board is engineered from rigid polyisocyanurate PIR insulation board with gas-tight foil facings on both sides.

Ideal for thermal insulation and creating slopes on restricted-access concrete, timber, or metal flat roof decks in new and refurbished buildings, this 130mm board serves multiple purposes.

When paired with a vapor control layer and a mechanically fixed single-ply roof waterproofing membrane, the 130mm Unilin FR/ALU Insulation Board achieves optimal performance.

Installation involves laying the boards over the vapor control layer in a break-bonded pattern for comprehensive coverage.

For secure installation, 130mm Unilin flat roof insulation boards must be fixed using approved mechanical fixings.

Roof Design

Follow the recommendations outlined in BS 4841: Part 3 and guidance from the Single Ply Roofing Association.

Falls

Flat roofs require a constant and adequate fall to prevent water pooling from rainfall.

Fire Performance

Fire rating, when tested to EN 13501-5 and BS 476 Part 3 'External Fire Exposure Roof Test', depends on the waterproofing system selected.

Note: This board was formerly known as 130mm Xtratherm Thin-R FR/ALU Flat Roof PIR Insulation Board
