140mm Unilin FR/ALU Flat Roof Insulation Board

140mm Unilin FR/ALU, previously branded as 140mm Xtratherm FR/ALU, is a premium Polyisocyanurate flat roof insulation solution with vapour-tight aluminium foil facings. This product integrates seamlessly with single-ply membranes and forms part of Unilin's comprehensive range of high-performance flat roof boards, delivering complete solutions for flat roof applications.

Product specification

Brand: Unilin Insulation FR/ALU (formerly Xtratherm FR/ALU)

Model: 140mm Unilin FR/ALU

Thickness: 140mm

Available Thicknesses: 25mm, 30mm, 40mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 125mm, 130mm, 140mm, 150mm

Length: 2400mm

Width: 1200mm

Board Coverage: 2.88m2

Pack Coverage: 5.76 m2

Pack Quantity: 2 sheets

Pack Weight: 26 kg

Dimensions: 2,400mm x 1,200mm x 140mm

Thermal Conductivity: 0.022 W/mK

R-Value: 6.36 m2K/W

Colour: Light yellow

Density: 32 Kg/m3

Compressive Strength: > 150kPa

Material: Polyisocyanurate Rigid Foam ( PIR insulation board )

Profile: Square Edge

Fire Reaction: Euroclass B, s2-d0

Finish: Vapour resistant gas-tight foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Applications: Flat Roof Waterproofing Systems

BBA Certified: Yes (No. 11/4817)

Fixing method: Mechanically fixed single ply waterproofing systems

Foil faced: Yes, gas-tight foil facings on both sides

Features: Composite gas-tight foil facings on both sides

Manufacturer: Unilin Insulation®

Main Highlights:

1. Outstanding thermal performance and efficiency
2. Gas-tight foil facers delivering superior vapour resistance
3. Compatible with mechanically fixed single-ply systems
4. Environmental Product Declaration (EPD) certified by IGBC. Contact our technical support team for further details.

Advantages:

1. Outstanding thermal performance and efficiency
2. Works with mechanically fixed single-ply systems and loose-laid ballasted systems
3. Superior vapour resistance from dual foil facers
4. Includes Environmental Product Declaration (EPD) certified by IGBC. Speak with our technical support team for additional information.

About

The 140mm Unilin FR/ALU Flat Roof Insulation Board features rigid polyisocyanurate construction with PIR insulation technology and gas-tight foil facings on both sides.

Engineered for thermal insulation and slope creation on restricted-access concrete, timber, or metal flat roof decks in new and refurbished properties, this board delivers dual functionality.

When paired with a vapour control layer and a mechanically fixed single-ply roof waterproofing membrane, the 140mm Unilin FR/ALU board achieves optimal performance.

Installation involves laying boards over the vapour control layer in a staggered pattern for complete coverage. Secure the 140mm Unilin flat roof insulation boards using approved mechanical fixings.

Roof Design

Follow the guidance in BS 4841: Part 3 and the Single Ply Roofing Association recommendations.

Falls

Flat roofs require consistent, adequate falls to prevent water pooling and ensure proper drainage.

Fire Performance

Fire rating, when tested to EN 13501-5 and BS 476 Part 3 'External Fire Exposure Roof Test', depends on the waterproofing system selected.

Note: This board was previously known as 140mm Xtratherm Thin-R FR/ALU Flat Roof PIR Insulation Board
