60mm Unilin FR/ALU Flat Roof Insulation Board

60mm Unilin FR/ALU is a premium Polyisocyanurate flat roof insulation with gas-tight aluminium foil facings on both sides, engineered for compatibility with single-ply membranes. This product forms part of Unilin's comprehensive range of high-performance flat roof boards, delivering complete solutions tailored for flat roof applications.

Product specification

Brand: Unilin Insulation FR/ALU

Model: 60mm Unilin FR/ALU

Thickness: 60mm

Thickness: 25mm, 30mm, 40mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 125mm, 130mm, 140mm, 150mm

Length: 2400mm

Width: 1200mm

Board Coverage: 2.88m2

Pack Coverage: 14.40m2

Pack Quantity: 5 sheets

Pack Weight: 30 kg

Dimensions: 2,400mm x 1,200mm x 60mm

Thermal Conductivity: 0.022 W/mK

R-Value: 2.27 m2K/W

Colour: Light yellow

Density: 32 Kg/m3

Compressive Strength: > 150kPa

Material: Polyisocyanurate Rigid Foam ( PIR insulation board )

Profile: Square Edge

Fire Reaction: Euroclass B, s2-d0

Finish: Vapour resistant gas-tight foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Applications: Flat Roof Waterproofing Systems

BBA Certified: Yes (No. 11/4817)

Fixing method: Mechanically fixed single ply waterproofing systems

Foil faced: Yes, gas-tight foil facings on both sides

Features: Composite gas-tight foil facings on both sides

Manufacturer: Unilin Insulation®

Main Highlights:

1. Outstanding thermal performance
2. Foil facers delivering superior vapour control
3. Ideal for mechanically fixed single-ply applications
4. This product carries an Environmental Product Declaration (EPD) certified by IGBC. Contact our technical support for further details.

Advantages:

1. Outstanding thermal performance
2. Works seamlessly with mechanically fixed single-ply systems and loose-laid ballasted configurations
3. Superior vapour control via foil facers
4. Supplied with an Environmental Product Declaration (EPD) certified by IGBC. Reach out to our technical support team for additional information.

About

The 60mm Unilin FR/ALU Flat Roof Insulation Board utilises rigid polyisocyanurate PIR insulation with gas-tight foil facings on both sides.

Engineered for thermal insulation and creating slopes on restricted-access concrete, timber, or metal flat roof decks in new and refurbished buildings, the 60mm board serves multiple purposes.

When paired with a vapour control layer and a mechanically fixed single-ply roof waterproofing membrane, 60mm Unilin FR/ALU performs optimally.

Installing FR/ALU flat roof boards involves positioning them above the vapour control layer in a break-bonded arrangement for comprehensive protection.

For reliable installation, 60mm Unilin flat roof insulation boards must be secured using approved mechanical fasteners.

Roof Design

Reference BS 4841: Part 3 and Single Ply Roofing Association guidance when planning your roof structure.

Falls

Flat roofs require consistent falls that are sufficiently steep to prevent water pooling.

Fire Performance

Fire rating, when assessed under EN 13501-5 and BS 476 Part 3 'External Fire Exposure Roof Test', depends on the waterproofing system selected.

Note: This board was formerly known as 60mm Xtratherm Thin-R FR/ALU Flat Roof PIR Insulation Board
