120mm Unilin FR/ALU Flat Roof Insulation Board

120mm Unilin FR/ALU stands as a premium Polyisocyanurate flat roof insulation solution with vapor-tight aluminium foil facings, perfectly suited for single-ply membranes. This product forms part of Unilin's comprehensive range of performance-driven flat roof boards, delivering integrated solutions for flat roof applications.

Product specification

Brand: Unilin Insulation FR/ALU

Model: 120mm Unilin FR/ALU

Thickness: 120mm

Thickness: 25mm, 30mm, 40mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 125mm, 130mm, 140mm, 150mm

Length: 2400mm

Width: 1200mm

Board Coverage: 2.88m2

Pack Coverage: 8.64m2

Pack Quantity: 3 sheets

Pack Weight: 33 kg

Dimensions: 2,400mm x 1,200mm x 120mm

Thermal Conductivity: 0.022 W/mK

R-Value: 5.45 m2K/W

Colour: Light yellow

Density: 32 Kg/m3

Compressive Strength: > 150kPa

Material: Polyisocyanurate Rigid Foam ( PIR insulation board )

Profile: Square Edge

Fire Reaction: Euroclass B, s2-d0

Finish: Vapour resistant gas-tight foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Applications: Flat Roof Waterproofing Systems

BBA Certified: Yes (No. 11/4817)

Fixing method: Mechanically fixed single ply waterproofing systems

Foil faced: Yes, gas-tight foil facings on both sides

Features: Composite gas-tight foil facings on both sides

Manufacturer: Unilin Insulation®

Main Highlights:

1. Exceptional Thermal Efficiency
2. Foil facers providing effective vapor resistance
3. Suitable for mechanically fixed single-ply systems
4. This product has an Environmental Product Declaration (EPD) certified by IGBC. For additional information, please reach out to our technical support.

Advantages:

1. Exceptional Thermal Efficiency
2. Compatibility with mechanically fixed single-ply systems and loose-laid ballasted systems
3. Effective vapor resistance with foil facers
4. The product comes with an Environmental Product Declaration (EPD) certified by IGBC. For more information, please contact our technical support team.

About

The 120mm Unilin FR/ALU Flat Roof Insulation Board comprises rigid polyisocyanurate PIR insulation board with gas-tight foil facings on both surfaces.

Engineered for thermal insulation and slope creation on restricted-access concrete, timber, or metal flat roof decks in new and refurbished buildings, the 120mm Flat Roof Board FR/ALU delivers dual functionality.

When paired with a vapor control layer and mechanically fixed single-ply roof waterproofing membrane, 120mm Unilin FR/ALU Insulation Board achieves optimal performance.

Installation requires positioning boards over the vapor control layer in a break-bonded arrangement for comprehensive coverage.

For reliable installation, 120mm Unilin flat roof insulation boards must be secured using approved mechanical fixings.

Roof Design

Refer to the guidance in BS 4841: Part 3 and the Single Ply Roofing Association recommendations.

Falls

Flat roof falls should maintain consistent gradient, sloping sufficiently to prevent water pooling.

Fire Performance

Fire rating, determined by testing to EN 13501-5 and BS 476 Part 3 'External Fire Exposure Roof Test', depends on the waterproofing system selected.

Note: This board was formerly known as 120mm Xtratherm Thin-R FR/ALU Flat Roof PIR Insulation Board
