70mm Unilin FR/ALU Flat Roof Insulation Board

70mm Unilin FR/ALU is a premium Polyisocyanurate flat roof insulation with gas-tight aluminum foil facings, engineered for compatibility with single-ply membranes. Part of Unilin's comprehensive range of high-performance flat roof boards, this product delivers complete thermal solutions for flat roof applications.

Product specification

Brand: Unilin Insulation FR/ALU

Model: 70mm Unilin FR/ALU

Thickness: 70mm

Thickness: 25mm, 30mm, 40mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 125mm, 130mm, 140mm, 150mm

Length: 2400mm

Width: 1200mm

Board Coverage: 2.88m2

Pack Coverage: 11.52m2

Pack Quantity: 4 sheets

Pack Weight: 28 kg

Dimensions: 2,400mm x 1,200mm x 70mm

Thermal Conductivity: 0.022 W/mK

R-Value: 3.18 m2K/W

Colour: Light yellow

Density: 32 Kg/m3

Compressive Strength: > 150kPa

Material: Polyisocyanurate Rigid Foam ( PIR insulation board )

Profile: Square Edge

Fire Reaction: Euroclass B, s2-d0

Finish: Vapour resistant gas-tight foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Applications: Flat Roof Waterproofing Systems

BBA Certified: Yes (No. 11/4817)

Fixing method: Mechanically fixed single ply waterproofing systems

Foil faced: Yes, gas-tight foil facings on both sides

Features: Composite gas-tight foil facings on both sides

Manufacturer: Unilin Insulation®

Main Highlights:

1. Exceptional Thermal Efficiency
2. Foil facers providing effective vapor resistance
3. Suitable for mechanically fixed single-ply systems
4. This product has an Environmental Product Declaration (EPD) certified by IGBC. For additional information, please reach out to our technical support.

Advantages:

1. Exceptional Thermal Efficiency
2. Compatibility with mechanically fixed single-ply systems and loose-laid ballasted systems
3. Effective vapor resistance with foil facers
4. The product comes with an Environmental Product Declaration (EPD) certified by IGBC. For more information, please contact our technical support team.

About

The 70mm Unilin FR/ALU Flat Roof Insulation Board features rigid polyisocyanurate foam with gas-tight foil facings on both sides, delivering superior thermal performance.

Ideal for thermal insulation and creating roof slopes on limited-access concrete, timber, or metal flat roof decks in new and refurbished properties, this board offers dual functionality.

When paired with a vapor control layer and mechanically fixed single-ply roof waterproofing membrane, the 70mm Unilin FR/ALU performs optimally.

Installation involves laying boards over the vapor control layer in a break-bonded pattern for complete coverage.

For secure installation, 70mm Unilin FR/ALU flat roof insulation boards must be fixed using approved mechanical fasteners.

Roof Design

Follow the guidance outlined in BS 4841: Part 3 and recommendations from the Single Ply Roofing Association.

Falls

A flat roof should maintain consistent fall gradients, sloped sufficiently to prevent water pooling.

Fire Performance

Fire rating, when assessed to EN 13501-5 and BS 476 Part 3 'External Fire Exposure Roof Test', depends on the waterproofing system selected.

Note: This board was formerly known as 70mm Xtratherm Thin-R FR/ALU Flat Roof PIR Insulation Board
