30mm Unilin FR/ALU Flat Roof Insulation Board

30mm Unilin FR/ALU, previously known as 30mm Xtratherm FR/ALU, is a premium Polyisocyanurate flat roof insulation with vapor-tight aluminium foil facings on both sides. This product works seamlessly with single-ply membranes and forms part of Unilin's comprehensive range of high-performance flat roof boards for complete flat roof solutions.

Product specification

Brand: Unilin Insulation FR/ALU (formerly Xtratherm FR/ALU)

Model: 30mm Unilin FR/ALU

Thickness: 30mm

Available Thicknesses: 25mm, 30mm, 40mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 125mm, 130mm, 140mm, 150mm

Length: 2400mm

Width: 1200mm

Board Coverage: 2.88m²

Pack Coverage: 28.80m²

Pack Quantity: 10 sheets

Pack Weight: 40kg

Dimensions: 2,400mm x 1,200mm x 30mm

Thermal Conductivity: 0.022 W/mK

R-Value: 1.14 m²K/W

Colour: Light yellow

Density: 32 Kg/m³

Compressive Strength: > 150kPa

Material: Polyisocyanurate Rigid Foam (PIR insulation board)

Profile: Square Edge

Fire Reaction: Euroclass B, s2-d0

Finish: Vapour resistant gas-tight foil

Inner Facing: Foil Facing

Outer Facing: Foil Facing

Applications: Flat Roof Waterproofing Systems

BBA Certified: Yes (No. 11/4817)

Fixing Method: Mechanically fixed single ply waterproofing systems

Foil Faced: Yes, gas-tight foil facings on both sides

Features: Composite gas-tight foil facings on both sides

Manufacturer: Unilin Insulation®

Main Highlights:

1. Outstanding thermal performance and efficiency
2. Foil facers deliver superior vapour resistance
3. Ideal for mechanically fixed single-ply systems
4. Comes with an Environmental Product Declaration (EPD) certified by IGBC. Contact our technical support team for further details.

Advantages:

1. Outstanding thermal performance and efficiency
2. Works with mechanically fixed single-ply systems and loose-laid ballasted systems
3. Superior vapour resistance from foil facers
4. Includes an Environmental Product Declaration (EPD) certified by IGBC. Reach out to our technical support team for additional information.

About

The 30mm Unilin FR/ALU Flat Roof Insulation Board is manufactured from rigid polyisocyanurate PIR insulation with gas-tight foil facings on both sides.

This product delivers thermal insulation and slope enhancement for restricted-access concrete, timber, or metal flat roof decks in new construction and renovation projects alike.

When paired with a vapour control layer and a mechanically fixed single-ply roof waterproofing membrane, the 30mm Unilin FR/ALU board delivers optimal performance.

Installation requires laying the boards over the vapour control layer in a break-bonded pattern for complete coverage.

Secure the 30mm Unilin FR/ALU flat roof insulation boards using approved mechanical fixings to ensure proper placement.

Roof Design

Follow the guidance provided in BS 4841: Part 3 and the Single Ply Roofing Association recommendations.

Falls

Flat roofs must have consistent falls that are steep enough to prevent water pooling.

Fire Performance

Fire rating, when tested to EN 13501-5 and BS 476 Part 3 'External Fire Exposure Roof Test', depends on the waterproofing system selected.

Note: This board was formerly known as 30mm Xtratherm Thin-R FR/ALU Flat Roof PIR Insulation Board
