130mm Kingspan Thermaroof TR27 Flat Roof Insulation

130mm Kingspan Thermaroof TR27 is a premium flat roof insulation board engineered for roofs utilising fully adhered single-ply membranes, partially bonded built-up felt, mastic asphalt, or cold liquid applied waterproofing systems. This high-performance rigid polyisocyanurate product delivers exceptional thermal performance and integrates seamlessly with green roof systems. Installation is straightforward, making it suitable for both new builds and refurbishment applications.

The TR27 130mm board measures 1200mm by 1200mm.

Product Specification

Brand: Kingspan

Model: 130mm Thermaroof TR27

Thickness: 130mm

Length: 1200mm

Width: 1200mm

Weight: 5.31kg/m2

Pack Quantity: 3 sheets

Board Coverage: 1.44m2

**Pack Coverage: ** 4.32m2

Dimensions: 1,200mm x 1,200mm x 130mm

Colour: Light Yellow | Brownish

Compressive Strength: 150kPa

Density: 32kg/m3

Profile: Square edge

R-Value: 5.0 m2K/W

Has a thermal conductivity of: 0.027 W/mK (insulant thickness < 80 mm) 0.025 W/mK (insulant thickness 80 - 119 mm) 0.024 W/mK (insulant thickness ≥ 120 mm)

Finish: Faced on both sides with a coated glass tissue, autohesively bonded to the insulation core during manufacture.

Insulation Material: A high performance rigid thermoset polyisocyanurate (PIR insulation).

Application Temperature: from +5 °C to +25 °C

Shipping method: Articulated Vehicle ǀ Courier

Applications: Insulation for flat roofs waterproofed with fully adhered single-ply, partially bonded built-up felt, mastic asphalt and cold liquid applied waterproofing.

BBA Certified: Yes

Fire Reaction: Under System 4 AVCP, 130mm Thermaroof TR27 has a Euroclass rating of F.

Compressive Strength: typically exceeds 150 kPa at 10% compression.

Features: High performance flat roof insulation board

Product Highlights:

1. Delivers outstanding thermal efficiency, providing superior insulation performance for flat roofs.
2. Fully compatible with single-ply non-bituminous membranes when bonded using solvent-based adhesive systems, ensuring reliable performance.
3. Works effectively with bitumen-based and mastic asphalt waterproofing systems, offering installation flexibility across multiple approaches.
4. Integrates with most green roof systems, supporting sustainable roofing design options.
5. Available with FM Approval to FM 4470, meeting recognised industry compliance standards.
6. Supplied as a tapered insulation system option, enabling proper roof drainage and slope creation.
7. Simple to handle and install, reducing labour time and project duration.
8. Pre-bonded boards (TR27PB) are available, further accelerating installation schedules. Contact our roofing insulation team for details and support.

Applications

130mm Kingspan TR27 accommodates various installation configurations to match different building requirements. Recommended installation methods include:

1. Dense Concrete Deck with Suspended Ceiling: Suitable for dense concrete decks paired with suspended ceiling systems.
2. Timber Deck with Plasterboard Ceiling: Appropriate for timber deck installations combined with plasterboard ceiling finishes.
3. Metal Deck with No Ceiling: Designed for metal deck applications without ceiling requirements.
4. Extensive Green Roof Covering - Metal Deck with No Ceiling: Tailored for extensive green roof systems on metal decks without ceiling installation.
5. Semi-intensive Green Roof Covering - Dense Concrete Deck with Suspended Ceiling: Engineered for semi-intensive green roof systems with dense concrete decks and suspended ceiling configurations.
6. These options provide adaptability across diverse structural types and architectural specifications.
