40mm Unilin Thin-R FR/MG Flat Roof Insulation

40mm Unilin FR/MG Flat Roof Insulation Board is a high-performance Polyisocyanurate product featuring mineral-coated glass facers, engineered for use beneath single-ply waterproofing systems and partially bonded built-up felt installations.

These 40mm roof insulation boards are installed using approved mechanical fixings or suitable adhesive bonding. Assessment of vapour control layer requirements must be undertaken in line with relevant Building Regulations.

40mm Unilin Thin-R FR/MG was previously known as 40mm Xtratherm Thin-R FR/MG.

Product Specification

Brand: Xtratherm / Unilin ®

Model: 40mm FR/MG

Thickness: 40mm

Length: 1200mm

Width: 600mm

Dimensions: 1,200mm x 600mm x 40mm

Board Coverage: 0.72m2

Pack Coverage: 8.64m2

Pack Quantity: 12

Density: 30kg/m3

Colour: Cream

Material: Polyisocyanurate (PIR Insulation)

Profile: Square Edge

R-Value: 1.04m2K/W

Thermal Conductivity: 0.024W/mK

Compressive strength: CS (10\Y) 150

Reaction to fire: Euroclass E

Inner facing: Mineral glass facer

Outer facing: Mineral glass facer

Shipping method: Articulated Vehicle ǀ Courier

Applications: Flat Roof Insulation

BBA Certified: Yes (No. 11/4878)

Features: Mineral coated glass facers

Advantages:

1. 40mm Unilin FR-MG delivers exceptional thermal performance
2. Works effectively with adhesively bonded single-ply roofing membranes when installed on mechanically fixed or bonded boards.
3. Environmental Product Declaration (EPD) certification from IGBC is available for this product.

Roof Design

Reference should be made to the guidance in BS 4841: Part 3 and the Single Ply Roofing Association recommendations.

Falls

Flat roofs must incorporate consistent falls with sufficient gradient to prevent water pooling.

Fire Performance

The fire classification of our 40mm Unilin FR-MG, when assessed to EN 13501-5 and BS 476 Part 3 'External Fire Exposure Roof Test', will depend on the waterproofing system selected.

Vapour Control Layer

An approved, continuous vapour control layer is required beneath the insulation (except over sealed metal deck systems). For mechanically fixed boards, use a minimum 1000 gauge polythene vapour control layer, lapped and sealed with double-sided tape beneath the Roof insulation. The VCL must be extended up vertical upstands and around penetrations, sealed to fully encase the insulation layer before roof completion.
