Unilin Thin-R TR/BGM 90-110mm Tapered Roof Board

90-110mm Unilin Thin-R TR/BGM Tapered Flat Roof Insulation Board is a high-performance polyisocyanurate tapered roof insulation solution with polypropylene fleece finished bitumen/glass fibre on one face and mineral glass facing on the reverse (non-reversible). The Unilin TR-BGM variant delivers optimal performance with most bitumen-based partially bonded built-up roofing systems.

This product forms part of Unilin's comprehensive range of tapered roof boards, delivering complete solutions for sloped roof applications. An Environmental Product Declaration (EPD), verified by the IGBC, is available upon request. Contact our technical support team for further details.

Product Specification

Range: 90-110mm TR/BGM

Thickness: 30-50mm, 50-70mm, 70-90mm, 90-110mm (1:60)

Length: 1200mm

Width: 1200mm

Board Size: 1200mm x 1200mm

Pack Size: 4 sheets

Pack Coverage: 5.76

Pack Weight: 12kg

Thermal conductivity: 0.024 – 0.027 (WmK)

Compressive Strength: >150 kPa @ 10% compression

Material: PIR

Inner facing Mineral Glass

Outer facing Bitumen/glass fibre

Application: Flat Roof insulation

Density (Foam Core): 32 kg/m3

Reaction to Fire: Euroclass E

Features & Benefits

1. Dimensions: 1200mm length x 1200mm width x 90-110mm thickness
2. Fall gradient: 1:60
3. Appropriate for both refurbishment and new build projects
4. Designed for full bonding with approved adhesive systems
5. Environmentally responsible: Zero Ozone Depletion Potential (ODP), Low Global Warming Potential (GWP), and non-deleterious composition
6. Compressive Strength: >150 kPa @ 10% compression
7. Compatible with adhesively bonded single ply roofing membranes on mechanically fixed boards
8. Individual board coverage: 1.44m²
9. Pack provides four boards with total coverage of 5.76m²
10. Foam core density: 32kg/m³

Additional Features and Benefits

1. Suitable for both refurbishment and new construction applications
2. Delivers excellent dimensional stability and long-term durability
3. Simple installation and complete bonding using approved adhesives
4. Environmentally conscious product with zero ODP and minimal GWP
5. Meets non-deleterious materials requirements
6. Robust compressive strength for load-bearing applications
7. Compatible with adhesively bonded single ply roofing membranes
8. Efficient area coverage per board
9. Premium foam core with 32kg/m³ density ensures consistent performance

Vapour control layer

A vapour control layer, lapped and sealed, should be installed beneath the insulation board. When applying fully adhered systems, board joints must be taped according to the adhesive system specifications.

Bonded boards

The insulation boards are set within a bitumen layer on 3G type felt compliant with BS EN 13707: 2013 (Flexible sheets for waterproofing. Reinforced bitumen sheets for roof waterproofing) and adhered to the substrate. Unilin recommends all systems incorporate mechanical fixings or be secured using suitable adhesive products.
