Unilin Thin-R TR/BGM 30-50mm Tapered Roof Board

30-50mm Unilin Thin-R TR/BGM Tapered Flat Roof Insulation Board is a high-performance polyisocyanurate tapered roof insulation solution with a polypropylene fleece finished bitumen/glass fibre working surface on one side and mineral glass facing on the other (non-reversible). This product delivers optimal performance when integrated with bitumen-based partially bonded built-up roofing systems.

Manufactured by Unilin, this tapered roof board represents a comprehensive solution for tapered roof applications. An Environmental Product Declaration (EPD), certified by the IGBC, is available for this product. Contact our technical support team for further details.

Product Specification

Range: 30-50mm TR/BGM

Thickness: 30-50mm, 50-70mm, 70-90mm, 90-110mm (1:60)

Length: 1200mm

Width: 1200mm

Board Size: 1200mm x 1200mm

Pack Size: 6 sheets

Pack Coverage: 8.64

Pack Weight: 12kg

Thermal conductivity: 0.024 – 0.027 (WmK)

Compressive Strength: >150 kPa @ 10% compression

Material: PIR

Inner facing Mineral Glass

Outer facing Bitumen/glass fibre

Application: Flat Roof insulation

Density (Foam Core): 32 kg/m3

Reaction to Fire: Euroclass E

Features & Benefits

1. Dimensions: 1200mm length x 1200mm width x 30-50mm thickness
2. Fall: 1:60
3. Appropriate for both refurbishment and new build applications
4. Designed for full bonding with approved adhesive systems
5. Environmentally responsible: Zero Ozone Depletion Potential (ODP), Low Global Warming Potential (GWP), and non-deleterious composition
6. Compressive Strength: >150 kPa @ 10% compression
7. Works effectively with adhesively bonded single ply roofing membranes on mechanically fixed boards
8. Individual board coverage: 1.44m²
9. Six-board pack delivers total coverage of 8.64m²
10. Foam core density: 32kg/m³

Additional Benefits

1. Suitable for both refurbishment and new construction projects
2. Delivers excellent dimensional stability and long-term durability
3. Straightforward installation with full bonding using approved adhesives
4. Environmentally conscious product with zero ODP and minimal GWP
5. Meets non-deleterious materials requirements
6. Robust compressive strength for sustained load-bearing performance
7. Compatible with adhesively bonded single ply roofing membranes
8. Achieves substantial area coverage per board
9. Premium foam core with 32kg/m³ density ensures reliable performance

Vapour Control Layer

A vapour control layer, lapped and sealed, should be installed beneath the insulation board. For fully adhered systems, board joints require taping in accordance with the adhesive system specifications.

Bonded Boards

The insulation boards are embedded within a bitumen layer on 3G type felt to BS EN 13707: 2013 (Flexible sheets for waterproofing. Reinforced bitumen sheets for roof waterproofing adhered to the deck). Unilin recommends that all systems incorporate mechanical fixings or be secured using suitable adhesive alternatives.
