122.5mm Unilin XT/TL Insulated Plasterboard

Unilin Insulation | The new name for Xtratherm Insulation in the UK & Ireland.

122.5mm Thin-R Thermal Liner XT/TL Insulated Plasterboard (Dot & Dab) combines a Unilin 110mm PIR insulation core with two composite kraft facings. These facings bond to 12.5mm tapered edge plasterboard using a proprietary adhesive system.

Engineered for internal wall applications, this product features composite kraft facing on both sides with an integral vapour control layer to minimise condensation risk. The Thin-R Thermal Liner delivers superior thermal performance alongside drylining in a single installation, making it ideal for new builds and renovation work.

Properties

Brand: Unilin

Thickness: 122.5mm

Model: 122.5mm XT/TL Dot&Dab

Dimensions: 2400mm x 1200mm x 122.5mm

Compressive Strength: 150 kPa

Density: 30-32 Kg/m3

Material: PIR core ǀ Gypsum plasterboard

Profile: Tapered edge plasterboard

R-Value: 5.06 m2K/W

Thermal Conductivity: 0.022 W/mk

Vapour Resistivity: 100 MNs/gm

Finish: Composite Kraft facings

Reaction To Fire: Euroclass B s1 d0

Applications: Internal walls ǀ Pitched and flat roofs

Vapour Control Layer: Yes, build in

Fixing method: Adhesive bonding

Features: PIR Thermal Insulated Plasterboard

Type: Thermal Liner®

Flexural Strength: ≥160N Transverse / ≥400N Longitudinal

Benefits

1. Insulation & Drylining in one application
2. Provides effective vapour control layer
3. Reduced insulation thickness
4. Suitable for a variety of wall Insulation types

About

The 122.5mm Thermal Liner XT/TL delivers comprehensive thermal insulation and drylining in a single operation, offering an excellent choice for new construction and refurbishment schemes. This solution enhances your home's energy efficiency whilst delivering reduced energy bills and improved comfort levels.

This 122.5mm Insulation Board is chemically stable and safe in use, manufactured with a blowing agent featuring zero Ozone Depletion Potential (ODP) and minimal Global Warming Potential (GWP).

Upgrading your home's energy performance delivers substantial advantages, including lower heating costs and enhanced living comfort. Thin-R Thermal Liner represents an effective solution for achieving these improvements and boosting your property's thermal efficiency.

The PIR board offers fire resistance benefits through continuous adhesive ribbons, particularly around openings such as windows and doors.

What are Insulated Plasterboards?

The 122.5mm XT/TL insulated plasterboards ( 110mm insulation + 12.5mm plasterboard ) combine plasterboard with an integrated insulation layer, typically manufactured from PIR Insulation. The insulation layer bonds to the plasterboard, creating a unified, multi-purpose panel that offers both thermal performance and a finished surface. These panels are widely used in construction to enhance thermal and sound insulation, whilst streamlining and accelerating installation. Applications include walls, ceilings, and floors, with various sizes and thicknesses available to meet specific building needs.
