Kingspan Thermafloor TF70 50mm Floor Insulation

50mm Kingspan Thermafloor TF70 delivers outstanding thermal performance as a floor insulation board, with a thermal conductivity rating of 0.022 W/mK. Suitable for both solid and suspended floor applications, this product works equally well in new builds and refurbishment schemes. The 50mm insulation boards cut and handle with ease, making installation straightforward. Multiple thickness options are available to match your project specifications.

Among the most thermally efficient 50mm floor insulation boards, this lightweight product offers simple transport, handling, and installation. It integrates seamlessly with most underfloor heating systems, helping to reduce associated costs including ground preparation and service routing.

Properties

Brand: Kingspan

Thickness: 50mm

Length: 2400mm

Width: 1200mm

Weight: 1.84kg | Thermafloor TF70 has an approximate weight of 3.50 kg/m2 at a thickness of 50 mm.

Model: 50mm Thermapitch TF70

Dimensions: 2,400mm x 1,200mm x 50mm

Compressive Strength: The compressive strength typically exceeds 140 kPa at 10% compression.

Density: 32 Kg/m3

Length: 2400mm

Material: Polyisocyanurate (Kingspan PIR Insulation)

R-Value: 2.25m2K/W

Size: 1200mm x 2400mm

Thermal Conductivity: 0.022 W/mk

Finish: 50mm TF70 is faced on both sides with a low emissivity composite foil, autohesively bonded to the insulation core during manufacture.

Applications: High performance floor insulation.

Fire Resistance: Under System 4 AVCP, 50mm Thermafloor TF70 has a Euroclass rating of F.

Water vapour resistance: 110 MNs/g

BBA Certified: Yes, No. 14/5133

Features: Improves the Thermal Resistance | Unaffected by air infiltration | Resistant to the passage of water vapour

Here are some "Applications":

The 50mm insulation suits a broad spectrum of applications, from solid concrete ground-based floors through to beam and dense block floors, suspended timber ground floors, and timber floors on battens.

The Facings

During manufacture, Kingspan 50mm PIR receives a low emissivity composite foil facing on both sides. This reflective layer boosts thermal resistance in any unventilated cavity adjacent to the board.

The Core

The 50mm Kingspan Thermafloor TF70 core employs Nilflam® technology, a premium fibre-free rigid thermoset polyisocyanurate (PIR) insulating material. Production uses a zero Ozone Depletion Potential (ODP) blowing agent with minimal Global Warming Potential (GWP).

Compressive Strength

When assessed to BS EN 826:2013 (Thermal insulating products for building applications. Determination of compression behavior), 50mm Kingspan PIR insulation typically achieves compressive strength exceeding 150 kPa at 10% compression.

Water vapour resistance

Testing to BS EN 12086:2013 (Thermal insulating products for building applications. Determination of water vapor transmission properties) demonstrates this product typically delivers water vapour resistance well above 100 MNs/g.

Durability

The longevity of 50mm TF70 Floor Insulation relies on correct installation, adequate structural support, and appropriate use conditions. With proper installation, the product can perform indefinitely.

Fire performance

50mm Kingspan Insulation* TF70 achieves an F Euroclass rating under System 4 AVCP. When installed in pitched roof applications beneath suitable roof covering, it meets national requirements for external fire exposure.
