Kingspan Thermafloor TF70 100mm Floor Insulation

100mm Kingspan Thermafloor TF70 delivers outstanding thermal performance as a floor insulation board, with a thermal conductivity rating of 0.022 W/mK. Suitable for both solid and suspended floor applications, this product works equally well in new builds and refurbishment schemes. These 100mm insulation boards are straightforward to cut and position, making installation efficient and hassle-free. Multiple thickness options are available to match your specific project needs.

Among the most thermally effective 100mm floor insulation boards, this lightweight material is simple to transport, position, and fit. It integrates seamlessly with most underfloor heating arrangements, helping to minimise expenses on associated work such as ground preparation and utility routing.

Properties

Brand: Kingspan

Thickness: 100mm

Length: 2400mm

Width: 1200mm

Weight: 1.84kg | Thermafloor TF70 has an approximate weight of 3.50 kg/m2 at a thickness of 100 mm.

Model: 100mm Thermapitch TF70

Dimensions: 2,400mm x 1,200mm x 100mm

Compressive Strength: The compressive strength typically exceeds 140 kPa at 10% compression.

Density: 32 Kg/m3

Length: 2400mm

Material: Polyisocyanurate (Kingspan PIR Insulation)

R-Value: 4.50m2K/W

Size: 1200mm x 2400mm

Thermal Conductivity: 0.022 W/mk

Finish: 100mm TF70 is faced on both sides with a low emissivity composite foil, autohesively bonded to the insulation core during manufacture.

Applications: High performance floor insulation.

Fire Resistance: Under System 4 AVCP, 100mm Thermafloor TF70 has a Euroclass rating of F.

Water vapour resistance: 110 MNs/g

BBA Certified: Yes, No. 14/5133

Features: Improves the Thermal Resistance | Unaffected by air infiltration | Resistant to the passage of water vapour

Here are some "Applications":

This 100mm insulation suits numerous applications, from solid concrete ground-based floors and beam-and-block construction to suspended timber ground floors and timber joisted arrangements.

The Facings

During production, Kingspan 100mm PIR receives a low emissivity composite foil facing on both surfaces, which acts as a reflective barrier to boost thermal resistance in any unventilated cavity space adjacent to the board.

The Core

The 100mm Kingspan Thermafloor TF70 core employs Nilflam® technology, a premium fibre-free rigid thermoset polyisocyanurate (PIR) material. Manufacturing uses a blowing agent with zero Ozone Depletion Potential (ODP) and minimal Global Warming Potential (GWP).

Compressive Strength

When assessed to BS EN 826:2013 (Thermal insulating products for building applications. Determination of compression behavior), 100mm Kingspan PIR insulation typically achieves compressive strength exceeding 150 kPa at 10% compression.

Water vapour resistance

Under BS EN 12086:2013 (Thermal insulating products for building applications. Determination of water vapor transmission properties) assessment, this product generally demonstrates resistance well above 100 MNs/g.

Durability

The lifespan of 100mm TF70 Floor Insulation depends on correct installation, adequate structural support, and appropriate usage conditions. When properly installed, it can perform reliably for many decades.

Fire performance

100mm Kingspan Insulation TF70 achieves an F Euroclass rating under System 4 AVCP. When deployed in sloped roof applications beneath appropriate roof coverings, it satisfies national standards for external fire exposure.
