Kingspan Thermafloor TF70 60mm Floor Insulation

60mm Kingspan Thermafloor TF70 delivers outstanding thermal performance as a floor insulation board, with a thermal conductivity rating of 0.022 W/mK. Suitable for both solid and suspended floor applications, this product works equally well in new builds and refurbishment schemes. These 60mm insulation boards are straightforward to cut and position, making installation efficient and hassle-free. Multiple thickness options are available to match your specific project needs.

Amongst the most thermally efficient 60mm floor insulation boards, this lightweight product is straightforward to transport, position and fit. It integrates seamlessly with most underfloor heating systems, helping to minimise costs associated with groundworks and service routing.

Properties

Brand: Kingspan

Thickness: 60mm

Length: 2400mm

Width: 1200mm

Weight: 1.84kg | Thermafloor TF70 has an approximate weight of 3.50 kg/m2 at a thickness of 60 mm.

Model: 60mm Thermapitch TF70

Dimensions: 2,400mm x 1,200mm x 60mm

Compressive Strength: The compressive strength typically exceeds 140 kPa at 10% compression.

Density: 32 Kg/m3

Length: 2400mm

Material: Polyisocyanurate (Kingspan PIR Insulation)

R-Value: 2.70m2K/W

Size: 1200mm x 2400mm

Thermal Conductivity: 0.022 W/mk

Finish: 60mm TF70 is faced on both sides with a low emissivity composite foil, autohesively bonded to the insulation core during manufacture.

Applications: High performance floor insulation.

Fire Resistance: Under System 4 AVCP, 60mm Thermafloor TF70 has a Euroclass rating of F.

Water vapour resistance: 110 MNs/g

BBA Certified: Yes, No. 14/5133

Features: Improves the Thermal Resistance | Unaffected by air infiltration | Resistant to the passage of water vapour

Here are some "Applications":

The 60mm insulation suits a broad spectrum of applications, from solid concrete ground-based floors through to beam and dense block construction, suspended timber ground floors, and timber floors laid on battens.

The Facings

Throughout manufacture, Kingspan 60mm PIR receives a low emissivity composite foil facing on both surfaces. This reflective layer boosts the thermal resistance of any unventilated cavity positioned adjacent to the board.

The Core

60mm Kingspan Thermafloor TF70 utilises Nilflam® technology at its core, a premium fibre-free rigid thermoset polyisocyanurate (PIR) material. The manufacturing process employs a blowing agent with zero Ozone Depletion Potential (ODP) and minimal Global Warming Potential (GWP).

Compressive Strength

When assessed to BS EN 826:2013 (Thermal insulating products for building applications. Determination of compression behavior), 60mm Kingspan PIR insulation typically achieves compressive strength exceeding 150 kPa at 10% compression.

Water vapour resistance

Under BS EN 12086:2013 (Thermal insulating products for building applications. Determination of water vapor transmission properties) assessment, this product typically demonstrates resistance well above 100 MNs/g.

Durability

The lifespan of 60mm TF70 Floor Insulation depends on correct installation, adequate structural support, and appropriate usage. When properly installed, it can perform reliably for many decades.

Fire performance

60mm Kingspan Insulation TF70 achieves an F Euroclass rating under System 4 AVCP. When deployed in pitched roof applications with suitable roof covering, it meets national standards for external fire exposure.

Info

Browse our full Kingspan range and refine by thickness or coverage using the filters on the left. For advice on product suitability for your specific project, or to request a quantity discount quotation, please contact us on +4402038839057, email sales@insulationbee or use Live Chat - Lowest UK Insulation Prices.
