Kingspan Thermafloor TF70 120mm Floor Insulation

120mm Kingspan Thermafloor TF70 delivers outstanding thermal performance as a floor insulation board, with a thermal conductivity rating of 0.022 W/mK. This insulation board works effectively on both solid and suspended floor systems, making it ideal for new builds and refurbishment work alike. The 120mm boards are straightforward to cut and position, speeding up installation times. Multiple thickness options are available to match your specific project needs.

Among the most thermally efficient 120mm floor insulation boards, this lightweight product offers excellent transportability and ease of installation. It integrates seamlessly with most underfloor heating arrangements, potentially lowering expenses on associated work such as ground preparation and service routing.

Properties

Brand: Kingspan

Thickness: 120mm

Length: 2400mm

Width: 1200mm

Weight: 1.84kg | Thermafloor TF70 has an approximate weight of 3.50 kg/m2 at a thickness of 120 mm.

Model: 120mm Thermapitch TF70

Dimensions: 2,400mm x 1,200mm x 120mm

Compressive Strength: The compressive strength typically exceeds 140 kPa at 10% compression.

Density: 32 Kg/m3

Length: 2400mm

Material: Polyisocyanurate (Kingspan PIR Insulation)

R-Value: 5.45m2K/W

Size: 1200mm x 2400mm

Thermal Conductivity: 0.022 W/mk

Finish: 120mm TF70 is faced on both sides with a low emissivity composite foil, autohesively bonded to the insulation core during manufacture.

Applications: High performance floor insulation.

Fire Resistance: Under System 4 AVCP, 120mm Thermafloor TF70 has a Euroclass rating of F.

Water vapour resistance: 110 MNs/g

BBA Certified: Yes, No. 14/5133

Features: Improves the Thermal Resistance | Unaffected by air infiltration | Resistant to the passage of water vapour

Here are some "Applications":

This 120mm insulation suits a broad spectrum of floor types, from solid concrete bases to beam and block construction, suspended timber ground floors, and timber joisted systems.

The Facings

The manufacturing process bonds Kingspan 120mm PIR with a low emissivity composite foil on both surfaces, creating a reflective layer that boosts thermal resistance in unventilated cavities adjacent to the board.

The Core

The 120mm Kingspan Thermafloor TF70 core utilises Nilflam® technology, a premium fibre-free rigid thermoset polyisocyanurate (PIR) material. Production employs a blowing agent with zero Ozone Depletion Potential (ODP) and minimal Global Warming Potential (GWP).

Compressive Strength

Testing to BS EN 826:2013 (Thermal insulating products for building applications. Determination of compression behavior) demonstrates that 120mm Kingspan PIR insulation typically achieves compressive strength exceeding 150 kPa at 10% compression.

Water vapour resistance

Under BS EN 12086:2013 (Thermal insulating products for building applications. Determination of water vapor transmission properties) assessment, this product routinely demonstrates water vapour resistance well above 100 MNs/g.

Durability

The longevity of 120mm TF70 Floor Insulation relies on correct installation, adequate structural support, and proper use conditions. When properly fitted, the product can perform effectively for many decades.

Fire performance

120mm Kingspan Insulation TF70 achieves an F Euroclass rating under System 4 AVCP. When installed in pitched roof applications beneath appropriate roof coverings, it satisfies national standards for external fire exposure.
