IKO Enertherm ALU PIR Insulation Board 50mm

The IKO Enertherm ALU PIR Insulation Board at 50mm thickness delivers high-performance thermal insulation with a rigid polyisocyanurate foam core that contains no CFCs, HCFCs, or HFCs. Both surfaces feature a gas-tight aluminium composite facing with seven layers of reflective ALU cladding, providing exceptional durability. This 50mm Insulation Board has undergone rigorous testing to confirm its performance against water ingress, structural loads, corrosion, and thermal emissivity across demanding conditions.

Properties

Brand: IKO Enertherm®

Thickness: 50mm

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 50mm

MPN: 30 IKO ALU

Density: 32 kg/m3

Compressive strength at: 10% deformation: 175kPa (17.5ton/m²)

R-Value: 2.25m2K/W

Thermal Conductivity: 0.022 W/mk

Water vapour diffusion:: PIR foam: μ = 60 – ALU facing μ > 100,000

Applications: Roofs, Walls, Floors, Timber & Steel Frame

BBA Certified: Yes, No.15/5283

Features: Multi-functional ALU PIR Insulation

By Project Type: DIY, New Build, Refurbishment

Installation Method: Loose Laid, Mechanically Fixed, Partially Bonded

Material: PIR

Facing: Aluminium composite facing on both sides

Product Colour: Silver

Product Finish: Aluminium Multi Layer Lamination

Sector: Community & Amenity, Domestic, Education, Health, Hotel & Leisure, Industrial, Mixed Use, Offices, Private Housing, Retail, Social Housing, Utilities

Substrate: Concrete, Masonry Structure, Metal, Timber (Plywood-OSB)

Fire Performance: EN 13501-1: Class E | BS 476 – p7 : Class 1

Range Of Applications

1. Rooftop: Flat Roof Insulation for timber, concrete and steel deck.
2. Sarking: pitched roof insulation (type nF with neutral felt).
3. Floor: floor insulation (underfloor heating and concrete floors).
4. Wall: cavity wall insulation.
5. Wrap: outside wall insulation (closed joints).
6. Comfort: loft insulation.
7. Comfort Easy: Loft floor insulation.

This 50mm PIR board suits numerous applications including external walls, pitched roofs, floors, internal walls, inverted roofs, metal roofs, and flat roofs, delivering outstanding thermal performance. The insulation properties significantly boost energy efficiency and thermal resistance throughout your building, regardless of application type. Improved energy efficiency reduces heating and cooling costs—a practical benefit given today's energy pricing. These boards are also environmentally responsible, containing no CFCs, HCFCs, or HFCs, so they pose no environmental risk.

About

Pairing the 50mm PIR insulation board with Roof Membranes is straightforward, and the product maintains its insulating performance and build quality over extended periods thanks to excellent dimensional stability. The boards resist rot and mould growth, guaranteeing extended service life. With high thermal values and minimal thickness, these boards reduce overall build depth, maximising usable space in roofs, floors, or cavities.

Micro Cell Technology

IKO Enertherm features distinctive properties from its Micro Cell Technology (MCT), achieved through optimised raw material selection and production processes. This creates a highly refined cell structure within the insulation.

Shape retention: IKO Enertherm boards maintain dimensional stability superior to PIR Boards with standard foam structures and non-shrinking alternatives. This prevents thermal bridging and extends service life without compromising insulation effectiveness.

Moisture resistance: MCT technology in 50mm IKO insulation boards delivers very low long-term water absorption (< 0.6%) compared to alternative insulation products. The PIR boards remain rot and mould-resistant, preserving insulation value by eliminating weight gain from moisture uptake.

Pressure insulation: 50mm IKO PIR boards offer outstanding pressure resistance through high elasticity. MCT-engineered flexible cells prevent rupture and permanent indentation, even under foot traffic.
