60mm Unilin FR-BGM Flat Roof Insulation Board

The 60mm FR-BGM Flat Roof Insulation Board from Unilin incorporates a polypropylene fleece exterior layer combined with a bitumen and glass fibre working surface. A mineral glass facing protects the underside. This product belongs to Unilin's comprehensive range of high-performance 60mm flat roof boards, delivering integrated solutions for diverse flat roof applications.

60mm Unilin FR-BGM Flat Roof Board was previously known as 60mm Xtratherm FR-BGM.

Product Specification

Brand: Unilin / Xtratherm®

Model: 60mm FR/BGM

Thickness: 25mm,30mm,40mm, 50mm, 60mm, 70mm, 80mm, 100mm, 110mm, 120mm, 130mm, 140mm, 150mm

Length: 1200mm

Width: 600mm

Board Coverage: 0.72m2

Pack Coverage: 5.76 m2

Pack Quantity: 8

R-Value: 2.5m2K/W

Thermal Conductivity: 0.024W/mK

Compressive Strength: 150kPa

Dimensions: 1,200mm x 600mm x 60mm

Colour: Yellowish

Density: 32kg/m3

Material: Polyisocyanurate (PIR Insulation)

Profile: Square Edge

Inner facing: Mineral Glass

Outer facing: Bitumen/glass fibre

Shipping method: Articulated Vehicle ǀ Courier

Applications: Flat Roof

BBA Certified: Yes (No. 11/4878)

ETA Notification: Yes

Features: Thermally efficient flat roof board

About

The 60mm Unilin Thin-R FR-BGM represents a key element within Unilin's extensive portfolio of high-performance flat roof boards, delivering multiple advantages for flat roof construction:

1. Superior thermal efficiency: The 60mm FR-BGM delivers outstanding insulation capabilities, maintaining consistent internal building temperatures.
2. Wide system compatibility: Engineered for seamless integration with bituminous roofing systems, this board adapts readily to existing roof structures.
3. Durable fleece-finished surfaces: The polypropylene fleece-finished bitumen and glass fibre working surface enhances the durability and performance of the 60mm Flat Roof BGM, providing a robust, long-lasting installation.
4. Environmental Product Declaration accreditation: The 60mm Unilin Flat Roof Insulation Board BGM holds EPD certification from the IGBC (International Green Building Council). Contact the technical support team for comprehensive documentation.

Key Points:

1. Delivers exceptional thermal performance.
2. Incorporates fleece-finished bitumen and glass fibre facings.
3. FR-BGM permits direct application of torch on felt to the insulation surface.
4. Integrates with an extensive range of bituminous roofing systems.

Roof Design

The 60mm Unilin Insulation Boards are compatible with numerous bitumen-based waterproofing systems. These typically employ a BS EN 13707:2013 type 3G perforated base layer or proprietary roof waterproofing solutions. Position the fleece side facing upward during installation. Full bonding represents an alternative approach. Refer to BS 8217 guidance for managing moisture and condensation in reinforced bitumen membrane roofing applications.

Falls

Flat roof design must incorporate adequate fall to prevent water pooling.

Roof Loading

The 60mm Unilin FR/BGM boards suit roof decks with minimal foot traffic and infrequent maintenance requirements. Where regular pedestrian access occurs, install protective walkways. Following roof completion, lay protective boarding if additional site work is anticipated. This protects the roofing system's structural integrity.

Roof Finish

Built-up roofing systems require finishing with an appropriate reflective layer such as stone chippings. Consult the system manufacturer for specific recommendations.

Fire Performance

Fire rating, determined by EN 13501-5 and BS 476 Part 3 'External Fire Exposure Roof Test' assessment, depends on the selected waterproofing system.

Vapour Control Layer

Prime roof decks before applying hot bitumen for vapour control layer bonding. Consult BS 8217 for vapour control layer application procedures. Extend the VCL beyond the insulation and seal against the parapet wall.
