Unilin Safe-R SR/TB 112.5mm Phenolic Insulated Plasterboard

112.5mm Unilin Safe-R SR/TB Phenolic Insulated Plasterboard combines a high-performance 100mm phenolic insulation core with glass tissue facing, bonded to 12.5mm tapered edge plasterboard using specialist adhesive for internal wall applications.

This innovative product delivers outstanding thermal insulation and drylining in one step, making it an excellent choice for new builds and refurbishment projects alike. Upgrading your home's energy efficiency brings real benefits—lower heating bills and enhanced comfort throughout the year.

Product Details

Brand: Unilin

Model: 112.5mm SR/TB Phenolic Insulated Plasterboard

Thickness: 112.5mm

Dimensions: 2,400mm x 1,200mm x 112.50mm

Width: 1200mm

Length: 2400mm

Board Coverage: 2.88m2

Pack Coverage: 11.52 m2

Pack Quantity: 4

Material: Phenolic core ǀ Gypsum plasterboard

R-Value: 5 m2K/W

Thermal Conductivity: 0.020 – 0.021 – (0.023 Below 40mm) (W/mK) Phenolic only

Finish: Composite kraft facing

Inner facing: Kraft facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Internal Walls ǀ Roofs

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

Reaction to fire: Euroclass B s1 d0

Fixing method: Adhesive bonding

Decoration: Skim plaster

ETA Notification: Yes

Features: Integral vapour barrier thermal-liner

Main Highlights

1. Three-in-one composite solution for complete wall systems.
2. Integrated vapor control layer included.
3. Fast installation and efficient thermal performance.
4. Combines insulation and drylining in a single board.
5. Achieves Euroclass B-s1 d0 fire safety rating.
6. Ideal for new builds, retrofits, and renovation work.
7. Thinner profile reduces overall wall thickness.
8. Supports dot and dab fixing methods.
9. Excellent low thermal conductivity at 0.020 W/mK.
10. Compatible with various wall substrates.
11. Standard 2400mm x 1200mm board dimensions.
12. Premium phenolic insulation core technology.
13. Unifies insulation, drylining, and vapor protection.
14. Simple to handle and install on site.

Integral Vapor Control Layer

The composite glass tissue facing acts as a gas and vapor barrier, minimising condensation risks. When SR/TB joints are properly sealed and taped following drylining standards, you achieve a complete vapor control system.

Fire Stops

When drylining walls, fire stops must be installed at the top and bottom of each board, plus around all openings including doors and windows. These consist of continuous adhesive lines that prevent fire spread behind the insulation and reduce thermal bridging for improved wall U-Values.

Handling, Cutting, and Storage

This insulation board requires storage on a clean, level surface above ground and must be protected from weather exposure. Polythene wrapping alone provides insufficient outdoor protection. Handle carefully throughout storage and construction, and always wear appropriate personal protective equipment (PPE).
