Unilin Safe-R SR/TB-MF 37.5mm Phenolic Insulated Plasterboard

37.5mm Unilin Safe-R SR/TB-MF Phenolic Insulated Plasterboard is a high-performance composite panel combining a 25mm phenolic insulation core with glass tissue facing, bonded to 12.5mm tapered edge plasterboard using specialist adhesive. Designed for interior use, this product delivers thermal insulation and drylining in one integrated solution.

The 37.5mm SR/TB system provides outstanding thermal insulation performance alongside efficient drylining capabilities, making it an excellent choice for new builds and refurbishment projects. Investing in energy-efficient solutions like this can significantly reduce heating costs and enhance comfort throughout your property.

Product Details

Brand: Unilin

Model: 37.5mm SR/TB Phenolic Insulated Plasterboard

Thickness: 37.5mm

Dimensions: 2,400mm x 1,200mm x 37.50mm

Width: 1200mm

Length: 2400mm

Board Coverage: 2.88m2

Pack Coverage: 34.56m2

Pack Quantity: 12

Material: Phenolic core ǀ Gypsum plasterboard

R-Value: 1.15m2K/W

Thermal Conductivity: 0.020 – 0.021 – (0.023 Below 40mm) (W/mK) Phenolic only

Finish: Composite kraft facing

Inner facing: Kraft facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Internal Walls ǀ Roofs

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

Reaction to fire: Euroclass B s1 d0

Fixing method: Adhesive bonding

Decoration: Skim plaster

ETA Notification: Yes

Features: Integral vapour barrier thermal-liner

Main Highlights

1. Three-in-one integrated system for insulation and drylining.
2. Built-in vapor control layer for moisture management.
3. Quick installation and efficient thermal performance.
4. Combines insulation and drylining in a single application.
5. Achieves Euroclass B-s1 d0 fire safety rating.
6. Suitable for new construction, retrofits, and renovation work.
7. Minimal insulation thickness required.
8. Compatible with dot and dab fixing methods.
9. Excellent thermal conductivity rating of 0.020 W/mK.
10. Works with various wall substrates.
11. Standard 2400mm x 1200mm board dimensions.
12. Features high-performance phenolic insulation core.
13. Single board provides insulation, drylining, and vapor control.
14. Simple to handle and install.

Integral Vapor Control Layer

The composite glass tissue facing on SR/TB acts as an impermeable barrier to gas and moisture, minimising condensation risks. When joints are properly sealed and taped following standard drylining practices, a complete vapor control layer is created across the wall surface.

Fire Stops

When installing drylining systems, fire stops must be positioned at the top and bottom of each board, plus around all openings including doors and windows. These consist of continuous lines of adhesive that prevent fire spread behind the insulation and help reduce thermal bridging for improved wall U-Values.

Handling, Cutting, and Storage

PIR insulation boards should be kept on a clean, level surface above ground and protected from weather exposure. Polythene wrapping alone does not provide adequate outdoor protection. Take appropriate precautions during storage and on-site handling. Always wear suitable personal protective equipment (PPE) when working with insulation materials.
