37.5mm Speedline PIR Thermal Laminate

37.5mm Speedline insulated plasterboards deliver enhanced thermal performance for residential and commercial properties. Engineered with a fibre-free rigid polyisocyanurate (25mm PIR) core bonded to 12.5mm plasterboard at manufacture, this dual-function system combines insulation and internal finishing in one product, reducing labour time and installation complexity.

These boards demonstrate strong environmental credentials, featuring Zero Ozone Depletion Potential (ODP) and Zero Global Warming Potential (GWP). They contain no CFC or HCFC, making them an ecologically responsible choice for sustainable construction projects.

The lightweight composition of these 37.5mm insulation boards facilitates straightforward handling, cutting, and installation. A fine-toothed saw is recommended for cutting the insulated plasterboards. Using a timber batten or straightedge as a guide ensures accurate cuts whilst maintaining board stability during the cutting process.

Properties

Thickness: 37.5mm, 52.5mm, 62.5mm, 72.5mm

Width: 1200mm

Length: 2400mm

Board Coverage: 2.88m2

Density: 250kg/m3

Weight of 1m2: 9.38kg

Weight: 27kg

Thermal Conductivity: 0.022 W/mk (insulation) 0.19 W/mk (plasterboard)

Thermal Resistance: 1.12m2K/W

Compressive Strength: 140kPa

Material: Polyisocyanurate ( PIR Insulation ), Low emissivity foil

Compressive Strength: Excess 140kPa at yield (insulation only)

Moisture Vapour Resistance: Installed Value at 100 MNs/g

Fire Performance: Class B s1,d0

Key Features:

1. Integrated thermal and dry-lining solution for walls and roofs.
2. Economical and time-saving installation method.
3. Thermal insulation and internal finish applied in a single operation.
4. Applicable to new construction and existing building upgrades.
5. Broad suitability across diverse building applications.
6. Green Guide Rating A+ for sustainable construction practices.
7. Robust and long-lasting performance.
8. Meets or surpasses current building regulation standards.
9. Reduces condensation formation through vapour resistance and thermal bridging mitigation.
10. Speedline Thermal Laminates can be finished using taping & jointing or gypsum skim plaster methods.

Applications

Speedline 37.5mm Insulated Plasterboards provide flexible solutions across multiple construction scenarios:

New Builds: Enhance thermal performance in newly constructed residential and commercial properties.

Refurbishments: Improve energy efficiency in existing structures undergoing renovation work.

Building Element Upgrades: Increase thermal performance of walls or roofs in established buildings.

Mechanical Fixing: Secure installation onto timber battens for solid masonry wall applications.

Speedline Wall Liner System: Mechanically fix to the Speedline Wall Liner System on solid masonry walls for specialised insulation solutions.

Masonry Cavity Wall: Apply to masonry cavity walls for enhanced thermal insulation performance.

Pitched Roof Application: Suitable for pitched roof installations to optimise temperature regulation and energy efficiency.

Flat Roof Application: Deploy in flat roof systems to maximise insulation value and reduce heat loss.

The adaptability of Speedline Insulation boards enables deployment across diverse construction applications, delivering reliable thermal insulation performance.
