Speedline 52.5mm PIR Thermal Laminate Board

52.5mm Speedline insulated plasterboards deliver superior thermal performance for residential and commercial properties. These boards feature a fibre-free rigid polyisocyanurate (40mm PIR) core bonded to 12.5mm plasterboard at manufacture. This dual-function design combines thermal insulation with dry-lining in one product, reducing installation time and labour costs.

Environmental credentials are a key strength of this product. These boards carry Zero Ozone Depletion Potential (ODP) and Zero Global Warming Potential (GWP), with no CFC or HCFC content, making them an eco-conscious choice for sustainable building projects.

Lightweight construction ensures straightforward handling, cutting, and installation. A fine-toothed saw is recommended for cutting these insulation boards, with a wooden plank or ruler serving as a reliable cutting guide to maintain accuracy and stability during the process.

Properties

Thickness: 37.5mm, 52.5mm, 62.5mm, 72.5mm

Width: 1200mm

Length: 2400mm

Board Coverage: 2.88m2

Density: 250kg/m3

Weight of 1m2: 9.38kg

Weight: 27kg

Thermal Conductivity: 0.022 W/mk (insulation) 0.19 W/mk (plasterboard)

Thermal Resistance: 2.87m2K/W

Compressive Strength: 140kPa

Material: Polyisocyanurate ( PIR Insulation ), Low emissivity foil

Compressive Strength: Excess 140kPa at yield (insulation only)

Moisture Vapour Resistance: Installed Value at 100 MNs/g

Fire Performance: Class B s1,d0

Key Features:

1. Integrated solution for enhancing walls and roofs.
2. Economical and time-saving installation method.
3. Thermal insulation and internal finish applied in a single step.
4. Ideal for new construction and renovation work.
5. Broad range of applications across different project types.
6. Green Guide Rating A+ certification for sustainable building.
7. Robust and reliable long-term performance.
8. Meets or exceeds all current building regulation standards.
9. Reduces condensation formation through vapour resistance and thermal bridging prevention.
10. Speedline Thermal Laminates can be finished with either 'Taping & Jointing' or gypsum skim plaster.

Applications

Speedline 52.5mm Insulated Plasterboards provide flexible solutions across numerous construction scenarios:

New Builds: Enhance thermal performance in new construction projects from the outset.

Refurbishments: Improve energy efficiency in existing structures during renovation work.

Upgrading Existing Building Elements: Boost thermal performance of walls or roofs in established buildings.

Mechanical Fixing: Secure installation onto timber battens for solid masonry walls.

Speedline Wall Liner System: Mechanically fixed to the Speedline Wall Liner System for solid masonry applications.

Masonry Cavity Wall: Enhance thermal insulation in masonry cavity walls.

Pitched Roof Application: Regulate temperature and improve energy efficiency in pitched roof installations.

Flat Roof Application: Minimise heat loss and boost insulation performance in flat roof systems.

The adaptability of Speedline Insulation boards makes them suitable for diverse construction applications, delivering consistent thermal insulation benefits.

Info

Browse our Speedline range and refine by thickness or coverage using the left-hand filters. For project suitability advice or bulk quotations, contact us on +4402038839057 , email sales@insulationbee or use Live Chat - Lowest UK Insulation Prices. Recticel Insulation combines premium PIR manufacturing expertise with continuous innovation, developing advanced insulation solutions that enhance thermal performance and installation efficiency.
