62.5mm Speedline PIR Thermal Laminate Board

62.5mm Speedline insulated plasterboards deliver superior thermal performance for residential and commercial properties. Engineered with a fibre-free rigid polyisocyanurate (50mm PIR) core bonded to 12.5mm plasterboard at manufacture, this dual-function system combines insulation and internal finish in one product, reducing labour time and installation complexity.

These boards demonstrate environmental responsibility through Zero Ozone Depletion Potential (ODP) and Zero Global Warming Potential (GWP), with no CFC or HCFC content, minimising ecological impact.

The 62.5mm insulation boards are lightweight and straightforward to cut and position on site. A fine-toothed saw is recommended for cutting the insulated plasterboards. Using a timber batten or straightedge as a guide ensures accurate cuts whilst keeping the board stable during the process.

Properties

Thickness: 37.5mm, 52.5mm, 62.5mm, 72.5mm

Width: 1200mm

Length: 2400mm

Board Coverage: 2.88m2

Density: 250kg/m3

Weight of 1m2: 9.38kg

Weight: 29kg

Thermal Conductivity: 0.022 W/mk (insulation) 0.19 W/mk (plasterboard)

Thermal Resistance: 2.31m2K/W

Compressive Strength: 140kPa

Material: Polyisocyanurate ( PIR Insulation ), Low emissivity foil

Compressive Strength: Excess 140kPa at yield (insulation only)

Moisture Vapour Resistance: Installed Value at 100 MNs/g

Fire Performance: Class B s1,d0

Key Features:

1. Integrated thermal insulation and dry-lining solution for walls and roofs.
2. Economical and time-saving installation method.
3. Thermal performance and surface finish applied in a single step.
4. Appropriate for new construction and retrofit applications.
5. Broad range of project suitability.
6. Green Guide Rating A+ for sustainable building practice.
7. Robust and reliable long-term performance.
8. Meets or surpasses Building Regulations requirements.
9. Reduces condensation formation through vapour control and thermal bridge elimination.
10. Speedline Thermal Laminates can be finished with either taping and jointing or gypsum skim plaster.

Applications

Speedline 62.5mm Insulated Plasterboards provide comprehensive thermal solutions across diverse construction applications:

New Builds: Enhances thermal performance in new construction projects for improved energy efficiency.

Refurbishments: Ideal for upgrading energy performance in existing structures and heritage properties.

Building Element Upgrades: Improves thermal characteristics of walls and roofs in established buildings.

Mechanical Fixing: Securely fastens to timber battens on solid masonry walls for reliable installation.

Speedline Wall Liner System: Mechanically fixed to the Speedline Wall Liner System on solid masonry for specialised insulation.

Masonry Cavity Wall: Enhances thermal insulation in masonry cavity walls for improved performance.

Pitched Roof Application: Suitable for pitched roof installations to regulate temperature and reduce heat loss.

Flat Roof Application: Delivers enhanced insulation in flat roof systems, minimising thermal loss.

The adaptability of Speedline Insulation boards makes them suitable for a comprehensive range of construction scenarios, providing reliable thermal insulation performance.

Info

Browse our Speedline range and filter by thickness or coverage on the left-hand side of the page. For project-specific advice or bulk quotations, contact us by phone on +4402038839057, email sales@insulationbee or Live Chat - Lowest UK Insulation Prices. Recticel Insulation is a leading manufacturer of premium PIR products and a team of innovators dedicated to developing advanced insulation solutions that enhance thermal performance and ease of installation.
