100mm Unilin Safe-R SR/ST Soffit Board

The 100mm Unilin Safe-R SR/ST Soffit Insulation Board delivers excellent thermal and fire performance for structural ceiling applications across commercial and residential properties. This premium phenolic insulation board incorporates low emissivity foil facings for enhanced performance.

The 100mm SR/ST Soffit Board prioritises thermal efficiency over visual appeal. If you need both superior performance and a finished appearance, consider the 106mm Safe-R Soffit Plus alternative. This laminated option combines outstanding thermal properties with low-maintenance aesthetics and enhanced security features, allowing you to apply your chosen decorative finish.

Product Details

Brand: Unilin®

Model: 100mm Unilin Safe-R SR/ST

Thickness: 100mm

Length: 2400mm

Width: 1200mm

Pack Quantity: 4

Board Coverage: 2.88m2

Pack Coverage: 11.52m2

Pack Weight: 40kg

Dimensions: 2,400mm x 1,200mm x 100mm

Compressive Strength: >120 (kPa)

Material: Phenolic resins

Profile: Square Edge

R-Value: 5.0 m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass C s1 d0

Profile: Straight

Inner facing: Foil facing

Outer facing: Foil facing

Type: Phenolic Insulation

Shipping method: Articulated Vehicle ǀ Courier

Applications: Structural Ceiling ǀ Soffit

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

ETA Notification: Yes

Features: Accepts Decorative Finish

Benefits

1. Fire Insulation classification C-s1, d0
2. Foil Faced Finish
3. Reduced Thermal Bridging
4. Lower Lambda Value for Improved UValues

About

1. This 100mm Safe-R Soffit product offers flexible installation methods: direct fixing to concrete slabs, battens, or specialised fixing systems all deliver a consistent finish. The lightweight construction makes handling straightforward, enabling rapid and simple installation on site.
2. The 100mm SR/ST includes a foil facer that can be sealed securely with specialist foil tape (contact the Unilin Technical team for detailed installation advice).
3. When used for soffit applications in new builds or refurbishment projects, 100mm Safe-R Soffit achieves outstanding U-Values with minimal insulation depth. The product achieves an exceptionally low thermal conductivity rating of 0.020 W/mK and carries a Euroclass C fire rating.

Handling, Cutting, and Storage:

1. Unilin Soffit insulation should be positioned on a flat, clean surface elevated from ground level and protected from weather exposure.
2. Polythene wrapping alone does not provide adequate protection against environmental conditions.
3. Take care to prevent damage during both storage and the building process.
4. When working with insulation board, always use appropriate personal protective equipment (PPE).

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.
