56mm Unilin XtroLiner XO/STP PIR Soffit Board

56mm Unilin XtroLiner XO/STP PIR Soffit Plus Insulation Board delivers outstanding thermal and fire performance for ceiling insulation in both commercial and residential properties.

This high-performance product combines a 50mm PIR insulation board with textured aluminium foil facings offering low emissivity properties. The pir insulation board is bonded to a robust 6mm building Board with superior impact resistance. This construction ensures long-lasting performance and creates an ideal substrate for applying decorative finishes.

Product Details

Brand: Unilin®

Model: 56mm Soffit PLUS

Thickness: 50mm PIR insulation bonded to 6mm Building Panel

Dimensions: 2,400mm x 1,200mm x 56mm

Length: 2400mm

Width: 1200mm

Pack Coverage: 57.60m2

Pack Quantity: 20 sheets

Material: PIR ǀ Building Board

Profile: Square Edge

R-Value: 2.35m2K/W

Thermal Conductivity: 0.021W/mK

Compressive Strength: >120 (kPa)

Fire Classification: Euroclass B-s1, d0

Board Type: Superior performance PIR Insulation

Type of finishing board: 6mm Building panel

Inner facing: Foil Facing

Outer facing: Foil Facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Structural Ceiling ǀ Soffit Insulation

BBA Certified: Yes (no. 12/4956)

Vapour Control Layer: Incorporated

Features: Decorative finish may be applied

Manufacturer: Unilin Xtroliner®

Highlighted Features

1. Resilient 6mm building panel with excellent impact resistance
2. Enhanced fire protection performance
3. Works well with a range of decorative finishes
4. Reduces thermal bridging
5. Superior thermal efficiency with lower lambda values

Handling, Cutting, and Storage Guidelines

1. Store your 56mm XtroLiner XO/STP Soffit Insulation Board indoors on a level, clean surface away from ground contact. Ensure adequate protection from weather and moisture.
2. Polythene wrapping alone cannot provide sufficient protection if the board is left exposed outdoors.
3. Take care when handling the pir insulation Board throughout storage and installation phases.
4. Always wear suitable Personal Protective Equipment (PPE) when working with this insulation.

Certifications and Standards

1. Holds BBA Certification No.12/4956.
2. Conforms to the BS EN ISO 9001 Quality Management System.
3. Adheres to the BS EN ISO 14001 Environmental Management System.
4. Complies with BS EN 13165 standards.

Typical Fixings Patterns
