Unilin Safe-R 86mm Phenolic Soffit Board

The Unilin Safe-R 86mm SR/STP Phenolic Soffit Insulation Board delivers dependable thermal and fire performance for ceiling applications in both commercial and residential properties. This premium 80mm phenolic insulation board features low emissivity aluminium foil facings and is firmly bonded to a 6mm building panel. The result is a tough, low-maintenance surface that's ready for decorative finishes whenever you need them.

Product Details

Brand: Unilin®

Model: 86mm SR/STP Soffit Board

Thickness: 86mm - 80mm Phenolic insulation + 6mm Building Panel

Length: 2400mm

Width: 1200mm

Pack Quantity: 12

Board Coverage: 2.88m2

Pack Coverage: 34.56m2

Pack Weight: 324kg

Dimensions: 2,400mm x 1,200mm x 86mm

Compressive Strength: >120 (kPa)

Material: Phenolic resins ǀ Building Panel

Profile: Square Edge

R-Value: 3.80m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass B s1 d0

Profile: Straight

Inner facing: Foil facing

Outer facing: Foil facing

Type: Phenolic Insulation

Type of finishing board: 6mm Building panel

Shipping method: Articulated Vehicle ǀ Courier

Applications: Structural Ceiling ǀ Soffit

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

ETA Notification: Yes

Features: Accepts Decorative Finish

About

1. The 86mm Unilin Safe-R SR/STP Phenolic Soffit insulation Board provides flexible installation methods: you can bond it straight to concrete slabs, fix it onto battens, or use proprietary fixing systems for a perfectly flat and level finish. Its lightweight, rigid construction makes fitting straightforward and hassle-free.
2. The bonded non-combustible building panel facing provides excellent water and impact resistance, safeguarding your decorative finishes for years to come.
3. For soffit applications in new builds or renovation work, the 86mm Safe-R Soffit Plus achieves outstanding U-Values with minimal thickness. It boasts an impressive thermal conductivity of 0.020 W/mK and carries a Euroclass B fire rating.

Advantages

1. Robust 80mm Phenolic insulation plus 6mm building panel with superior impact resistance.
2. Fire Classification B-s1, d0 compliant for enhanced safety performance.
3. Works seamlessly with decorative finishes for design flexibility.
4. Reduced thermal bridging supports better energy efficiency.
5. Low lambda value delivers improved U-Values.

Handling, Cutting, and Storage:

1. Unilin Soffit insulation should be stored on a clean, flat surface raised from ground level. Always protect it with a covering.
2. Polythene wrapping alone won't protect the insulation from weather exposure.
3. Take care to prevent damage during storage and throughout your build.
4. Wear suitable personal protective equipment (PPE) when handling the insulation board.

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.
