66mm Unilin Safe-R Phenolic Soffit Board

The 66mm Unilin Safe-R SR/STP Phenolic Soffit Insulation Board delivers dependable thermal and fire performance for structural ceiling applications in both commercial and residential properties. This premium 60mm phenolic insulation board features low emissivity aluminium foil facings bonded securely to a 6mm building panel. The result is a robust, low-maintenance surface that accepts decorative finishes beautifully.

Product Details

Brand: Unilin®

Model: 66mm SR/STP Soffit Board

Thickness: 66mm - 60mm Phenolic insulation + 6mm Building Panel

Length: 2400mm

Width: 1200mm

Pack Quantity: 18

Board Coverage: 2.88m2

Pack Coverage: 51.84m2

Pack Weight: 460kg

Dimensions: 2,400mm x 1,200mm x 66mm

Compressive Strength: >120 (kPa)

Material: Phenolic resins ǀ Building Panel

Profile: Square Edge

R-Value: 2.85m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass B s1 d0

Profile: Straight

Inner facing: Foil facing

Outer facing: Foil facing

Type: Phenolic Insulation

Type of finishing board: 6mm Building panel

Shipping method: Articulated Vehicle ǀ Courier

Applications: Structural Ceiling ǀ Soffit

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

ETA Notification: Yes

Features: Accepts Decorative Finish

About

1. This 66mm Unilin Safe-R SR/STP Phenolic Soffit insulation Board provides flexible installation methods: you can bond it directly to concrete slabs, fix it onto battens, or employ proprietary fixing systems for a perfectly flat, level finish. Its lightweight and rigid construction makes installation straightforward and efficient.
2. The bonded facing of the non-combustible building panel provides excellent water and impact resistance, protecting your decorative finishes for years to come.
3. When installing 66mm Safe-R Soffit Plus in soffit areas—whether for new builds or renovation work—you'll achieve outstanding U-Values with minimal insulation depth. The product delivers an exceptionally low thermal conductivity of 0.020 W/mK alongside a Euroclass B fire rating.

Advantages

1. Sturdy 60mm Phenolic insulation + 6mm building panel with outstanding impact resistance.
2. Fire Classification B-s1, d0 compliant for enhanced safety performance.
3. Works seamlessly with decorative finishes for design flexibility.
4. Reduced thermal bridging supports improved energy efficiency.
5. Low lambda value delivers superior U-Values.

Handling, Cutting, and Storage:

1. Unilin Soffit insulation should be kept on a clean, flat surface elevated from ground level and protected with a covering.
2. Polythene wrapping alone cannot adequately shield the insulation from weather exposure.
3. Take care to prevent damage during storage and throughout the building phase.
4. When working with the insulation board, always use appropriate personal protective equipment (PPE).

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.
