126mm Unilin Safe-R Phenolic Soffit Board

The 126mm Unilin Safe-R SR/STP Phenolic Soffit Insulation Board delivers excellent thermal performance and fire safety for structural ceiling applications in commercial and residential properties. This premium 120mm phenolic insulation board combines low emissivity aluminium foil facings with a bonded 6mm building panel for a robust, low-maintenance surface that accepts decorative finishes.

Product Details

Brand: Unilin®

Model: 126mm SR/STP Soffit Board

Thickness: 126mm - 120mm Phenolic insulation + 6mm Building Panel

Length: 2400mm

Width: 1200mm

Pack Quantity: 9

Board Coverage: 2.88m2

Pack Coverage: 25.92m2

Pack Weight: 270kg

Dimensions: 2,400mm x 1,200mm x 126mm

Compressive Strength: >120 (kPa)

Material: Phenolic resins ǀ Building Panel

Profile: Square Edge

R-Value: 6.0m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass B s1 d0

Profile: Straight

Inner facing: Foil facing

Outer facing: Foil facing

Type: Phenolic Insulation

Type of finishing board: 6mm Building panel

Shipping method: Articulated Vehicle ǀ Courier

Applications: Structural Ceiling ǀ Soffit

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

ETA Notification: Yes

Features: Accepts Decorative Finish

About

1. This 126mm Unilin Safe-R SR/STP Phenolic Soffit insulation Board provides flexible installation methods: attach directly to concrete slabs, fix onto battens, or use proprietary fixing systems for a perfectly level finish. The lightweight, rigid construction makes installation straightforward and efficient.
2. The non-combustible building panel bonded facing delivers water and impact resistance, providing durable protection and enabling the application of decorative finishes.
3. For soffit applications in new builds or renovation work, this 126mm Safe-R Soffit Plus achieves excellent U-Values with minimal thickness. It features an impressive thermal conductivity of 0.020 W/mK and carries a Euroclass B fire rating.

Advantages

1. Sturdy 120mm Phenolic insulation + 6mm building panel with outstanding impact resistance.
2. Fire Classification B-s1, d0 compliant for enhanced safety performance.
3. Suitable for decorative finishes to meet your design requirements.
4. Reduced thermal bridging for superior energy efficiency.
5. Low lambda value delivering improved U-Values.

Handling, Cutting, and Storage:

1. Unilin Soffit insulation should be stored on a clean, level, raised surface and protected from the weather.
2. Polythene wrapping alone does not provide adequate protection against weather exposure.
3. Take care to prevent damage during storage and on-site handling throughout construction.
4. Always use appropriate personal protective equipment (PPE) when handling the insulation board.

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.
