80mm Unilin Xtroliner XO/FB Frame Insulation

80mm Unilin Xtroliner XO/FB Framing Board is engineered for a range of construction applications, including both steel and timber frame systems, with structural heights up to 11 metres.

This flexible 80mm framing board offers multiple installation options - it can be positioned between studs or applied as an insulated sheathing board layer.

Using 80mm XO/FB Framing Board significantly minimises Thermal Bridging issues that typically occur with steel or timber studs.

Product Details

Brand: Unilin®

Dimensions: 2,400mm x 1,200mm x 80mm

SKU: 80mm XO/FB

Thickness: 50mm, 60mm, 75mm, 80mm, 100mm, & 120mm

Compressive Strength: 120 (kPa)

Length: 2400mm

Width: 1200mm

Pack Quantity: 4

Pack Coverage: 11.52m2

Material: 80mm PIR Insulation (polyisocyanurate)

Profile: Square Edge

R-Value: 3.80m2K/W

Thermal Conductivity: 0.021W/mK

Compressive Strength: >120 (kPa)

Density: 32kg/m3

Fire Classification: Euroclass C-s2, d0

Finish: Robust Textured Foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Timber or Steel Framing Systems

BBA Certified: Yes (no. 12/4956)

Vapour Control Layer: Incorporated

Foil faced: Yes, Both sides

Features: Reduced Thermal Bridging

Manufacturer: Xtratherm Xtroliner®

Highlighted Features

1. Suitable for both Steel and Timber Frame Systems
2. Low lambda value for improved thermal performance and U-Values
3. Ideal for both new construction and refurbishment work
4. Minimises Thermal Bridging effects
5. Durable textured foil surface
6. 80mm framing wall insulation board

Specification Clause

The selected wall insulation shall be 80mm XtroLiner XO/FB, manufactured to EN 13165 standards by Unilin Insulation. This wall insulation product features a durable modified Polyisocyanurate (PIR) core with textured, robust, low emissivity foil facings on both sides. The XtroLiner XO/FB variant has an Agrément declared Lambda value of 0.021 W/mK.

Resistance 'R' Values

To determine the resistance value for any thickness of Unilin 80mm PIR insulation, divide the material thickness (in metres) by the agrément declared lambda value. For example: Lambda 0.021 W/mK with 80mm thickness equals 0.080 ÷ 0.021, giving an R-Value of 3.80. Per EN 13165, R-Values should be rounded down to the nearest 0.05 (m2K/W).

Guidelines for Handling, Cutting, and Storage

1. Store 80mm Unilin XO/FB insulation on a clean, level surface above ground and protect from weather.
2. The polythene wrapping alone does not provide adequate protection against outdoor exposure.
3. Take care to protect the insulation during storage and throughout the building process.
4. Always use appropriate Personal Protective Equipment (PPE) when working with insulation materials.
