75mm Unilin Xtroliner XO/FB Frame Insulation

75mm Unilin Xtroliner XO/FB Framing Board is engineered for versatile construction applications, supporting both steel and timber frame systems with wall heights up to 11 metres.

This adaptable 75mm framing board works in two ways - positioned between studs or serving as an insulated sheathing board layer. Using 75mm XO/FB Framing Board significantly reduces thermal bridging issues commonly found in steel or timber stud construction.

Product Details

Brand: Unilin®

Dimensions: 2,400mm x 1,200mm x 75mm

SKU: 75mm XO/FB

Thickness: 50mm, 60mm, 75mm, 80mm, 100mm, & 120mm

Compressive Strength: 120 (kPa)

Length: 2400mm

Width: 1200mm

Pack Quantity: 4

Pack Coverage: 11.52m2

Material: 75mm PIR Insulation (polyisocyanurate)

Profile: Square Edge

R-Value: 3.55m2K/W

Thermal Conductivity: 0.021W/mK

Compressive Strength: >120 (kPa)

Density: 32kg/m3

Fire Classification: Euroclass C-s2, d0

Finish: Robust Textured Foil

Inner facing: Foil Facing

Outer facing: Foil Facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Timber or Steel Framing Systems

BBA Certified: Yes (no. 12/4956)

Vapour Control Layer: Incorporated

Foil faced: Yes, Both sides

Features: Reduced Thermal Bridging

Manufacturer: Xtratherm Xtroliner®

Highlighted Features

1. Compatible with Steel and Timber Frame Systems
2. Low lambda value for improved U-Values
3. Ideal for both Newbuild and Renovation projects
4. Minimises thermal bridging effects
5. Durable textured foil construction
6. 75mm framing wall insulation board

Specification Clause

The specified wall insulation will be 75mm XtroLiner XO/FB, manufactured to EN 13165 standards by Unilin Insulation. This wall insulation product features a robust modified Polyisocyanurate (PIR) core with textured, durable, low emissivity foil facings on both sides. The XtroLiner XO/FB variant carries an Agrément declared Lambda value of 0.021 W/mK.

Resistance 'R' Values

To determine the resistance value for any thickness of Unilin 75mm PIR insulation, divide the material thickness (in metres) by its Agrément declared lambda value. For example: Lambda 0.021 W/mK with 80mm thickness equals 0.080 ÷ 0.021, giving an R-Value of 3.80. Per EN 13165, R-Values must be rounded down to the nearest 0.05 (m2K/W).

Guidelines for Handling, Cutting, and Storage

1. Store 75mm Unilin XO/FB insulation on a clean, level surface above ground and protect with a cover.
2. Polythene wrapping alone does not provide adequate protection from weather exposure.
3. Monitor the insulation carefully during storage and throughout the building process.
4. Always use appropriate Personal Protective Equipment (PPE) when working with insulation materials.
