80mm Unilin Safe-R SR/CW Phenolic Cavity Insulation

80mm Unilin Safe-R SR/CW Phenolic Partial Fill Cavity Insulation Board offers an excellent solution for traditional masonry walls, delivering outstanding thermal performance whilst maintaining a protective air gap against wind-driven moisture.

Product Details

Brand: Unilin

Model: 80mm SR/CW Cavity Wall Insulation

Thickness: 80mm

Length: 1200mm

Width: 450mm

Pack Quantity: 4

Board Coverage: 0.54m2

Pack Coverage: 2.16m2

Pack Weight: 8kg

Dimensions: 1,200mm x 450mm x 80mm

Compressive Strength: >100 (kPa)

Material: Phenolic resins

Profile: Square Edge

R-Value: 3.80m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass D s1 d0

Finish: Low emissivity foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Traditional masonry walls

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

Features: BRE Green Guide A+ Rated

About

This 80mm SR/CW Phenolic Partial Fill Insulation Board is engineered to help you meet building regulation U-Values while keeping a residual cavity to guard against wind-driven rain. Partial fill masonry walls remain the standard construction approach for period properties, and 80mm SR/CW phenolic insulation provides an effective route when you need to achieve lower U-Values.

The excellent performance-to-thickness balance of 80mm SR/CW cavity wall insulation makes it possible to reach superior U-Values in period buildings without substantially widening the wall structure. By choosing 80mm SR/CW, you maintain the residual cavity, which acts as a reliable defence against moisture penetration.

Advantages

1. Phenolic insulation technology
2. Maintains a clear residual cavity
3. Protects against wind-driven rain
4. Features low thermal conductivity for improved U-Values
5. 80mm partial fill insulation board

Handling, Cutting, and Storage:

1. Unilin Cavity insulation should be positioned on a flat, clean surface elevated from ground level and protected by a weatherproof covering.
2. The polythene wrapping provides limited protection and should not be relied upon as the sole safeguard against weather exposure.
3. Take care to prevent damage to the insulation during storage and installation phases.
4. When working with insulation board, always use appropriate personal protective equipment (PPE).

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.

Info

Explore our full Unilin range and refine by thickness or coverage using the filters on the left. For guidance on product suitability for your project or to request a quantity discount quotation, contact us on +4402038839057, email sales@insulationbee or use Live Chat - Lowest UK Insulation board Prices.
