75mm Unilin Safe-R SR/FB Framing Insulation Board

The 75mm Unilin Safe-R SR/FB Framing Insulation Board is purpose-built for steel or timber frame construction up to 11 metres high. With Euroclass C Fire Classification, this board works brilliantly as an insulated sheathing board or between studs. The 75mm SR/FB Framing Insulation Board delivers outstanding U-Values and superior thermal bridging control for reliable building performance.

Product Details

Brand: Unilin®

Model: 75mm SR/FB Framing Board

Thickness: 75mm

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 75mm

Board Coverage: 2.88m2

Pack Coverage: 11.52m2

Pack Weight: 32kg

Pack Quantity: 4

R-Value: 3.55m2K/W

Thermal Conductivity: 0.021W/mK

Compressive Strength: >100 (kPa)

Type: Phenolic Insulation Board

Profile: Square Edge

Fire Classification: Euroclass C s1 d0

Finish: Low emissivity foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Steel and Timber Frame

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

Foil faced: Both sides

Features: Superior Performance Insulation

Benefits

1. Ideal for steel or timber frame systems reaching heights of up to 11 metres.
2. Lower thermal conductivity enhances overall U-Values.
3. Achieves Euroclass C-s1, d0 Fire Classification.
4. Reduces thermal bridging effectively.

Handling, Cutting, and Storage:

1. This Framing Insulation Board should be stored on a level, clean surface elevated from ground level and protected from the weather.
2. Polythene wrapping alone won't provide adequate protection from outdoor conditions.
3. Take care to prevent damage during storage and throughout your build.
4. Always use suitable personal protective equipment (PPE) when handling the insulation board.

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.
