60mm Unilin Safe-R SR/FB Framing Insulation Board

The 60mm Unilin Safe-R SR/FB Framing Insulation Board is engineered specifically for steel and timber frame construction reaching heights up to 11 metres. With Euroclass C Fire Classification, this product works brilliantly as an insulated sheathing board or between studs. The 60mm SR/FB Framing Insulation Board delivers outstanding U-Values and superior thermal bridging control for reliable construction performance.

Product Details

Brand: Unilin®

Model: 60mm SR/FB Framing Board

Thickness: 60mm

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 60mm

Board Coverage: 2.88m2

Pack Coverage: 14.40m2

Pack Weight: 40kg

Pack Quantity: 5

R-Value: 2.85m2K/W

Thermal Conductivity: 0.021W/mK

Compressive Strength: >100 (kPa)

Type: Phenolic Insulation Board

Profile: Square Edge

Fire Classification: Euroclass C s1 d0

Finish: Low emissivity foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Steel and Timber Frame

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes, build in

Foil faced: Both sides

Features: Superior Performance Insulation

Benefits

1. Ideal for steel and timber frame systems with heights up to 11 metres.
2. Lower lambda value improves thermal efficiency and U-Values.
3. Achieves Fire Classification C-s1, d0 for safety.
4. Reduces thermal bridging effectively.

Handling, Cutting, and Storage:

1. Store the Framing Insulation Board on a clean, level, raised surface and keep it under protective covering.
2. Polythene wrapping alone won't protect the insulation from weather exposure.
3. Take care to prevent damage during storage and throughout the building process.
4. Always use appropriate personal protective equipment (PPE) when handling the insulation board.

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.
