Unilin Safe-R SR/UF 100mm Phenolic Floor Board

100mm Unilin Safe-R SR/UF Phenolic Floor Insulation Board delivers premium rigid phenolic insulation with outstanding fire resistance. Featuring dual aluminium facings with low emissivity properties, this board achieves an excellent thermal conductivity of just 0.020 W/mK, enabling superior U-Values in flooring insulation systems.

Floors lose considerable heat downwards without adequate insulation protection. The 100mm Unilin SR/UF Phenolic Floor Insulation Board provides an effective solution, dramatically improving U-values for both new construction and existing floors. Beyond thermal performance, this board offers lightweight handling, simple installation, robust compressive strength, and minimal heat loss—combining to create a high-performance flooring insulation product.

Product Details

Brand: Unilin®

Model: 100mm SR/UF

Thickness: 100mm

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 100mm

Pack Coverage: 11.52m2

Board Coverage: 2.88m2

Pack Weight: 30kg

Pack Quantity: 4 Sheets

Compressive Strength: >150 (kPa)

Material: Phenolic resins

Profile: Square Edge

R-Value: 5.0 m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass D -s1, d0

Building Regulations: Compatible

Finish: Aluminium foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Floors ǀ Underfloor Heating Insulation

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes

Features: Underfloor Heating Insulation Board

Manufacturer: Unilin Safe-R®

Main Highlights

1. Reduced Insulation Thickness Requirements
2. Outstanding Compressive Strength Performance
3. Suitable for Underfloor Heating Systems
4. Reinforced Perimeter Strips for Enhanced Detailing
5. Superior U-values via Lower Lambda Values

Key Highlights

1. Holds BBA Certification.
2. Delivers Compressive Strength exceeding 150 (kPa).
3. Premium rigid phenolic insulation performance.
4. Achieves Euroclass D -s1, d0 fire classification.
5. Works seamlessly with Underfloor Heating (UFH).
6. Perfect for new builds, retrofits, and refurbishments.
7. Excellent thermal conductivity at 0.021 W/mK.
8. Minimises thermal bridging issues.
9. Reduces condensation risk.
10. Simple installation thanks to lightweight construction.
11. Integrated vapour control layer included.
12. Allows thinner insulation layers.
13. Standard board size of 2400mm x 1200mm (8 x 4).
14. Reinforced edge detailing with perimeter strips.
15. Enhanced U-values through optimised lambda values.
16. Handling, Cutting, and Storage Guidelines:
17. Store Unilin insulation on a clean, raised surface away from weather exposure.
18. Polythene wrapping alone does not provide adequate outdoor protection.
19. Take precautions during storage and construction to protect the insulation.
20. Always use appropriate Personal Protective Equipment (PPE) when handling insulation.
21. 100mm phenolic floor insulation board

Handling, Cutting, and Storage

Unilin Phenolic Insulation Board must be stored on an elevated, clean, level surface and kept protected from weather conditions. Polythene wrapping alone cannot provide sufficient protection from outdoor elements. Take appropriate care during storage and construction to maintain the insulation's integrity. Wear suitable personal protective equipment (PPE) when handling insulation materials.
