60mm Unilin Safe-R SR/UF Phenolic Floor Board

60mm Unilin Safe-R SR/UF Phenolic Floor Insulation Board delivers premium rigid phenolic insulation with outstanding fire resistance. Featuring dual aluminium facings with low emissivity properties, this board achieves an exceptional thermal conductivity of just 0.020 W/mK, enabling superior U-Values for flooring insulation systems.

Floors lose considerable heat downwards without adequate insulation protection. The 60mm Unilin SR/UF Phenolic Floor Insulation Board provides an effective solution, dramatically improving U-values for both new construction and existing properties. Beyond thermal performance, this board offers a lightweight design, straightforward fitting, excellent compressive strength, and minimal heat loss characteristics—combining to create a high-performance flooring insulation product.

Product Details

Brand: Unilin®

Model: 60mm SR/UF

Thickness: 60mm

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 60mm

Pack Coverage: 14.40m2

Board Coverage: 2.88m2

Pack Weight: 30kg

Pack Quantity: 5 Sheets

Compressive Strength: >150 (kPa)

Material: Phenolic resins

Profile: Square Edge

R-Value: 2.85 m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass D -s1, d0

Building Regulations: Compatible

Finish: Aluminium foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Floors ǀ Underfloor Heating Insulation

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes

Features: Underfloor Heating Insulation Board

Manufacturer: Unilin Safe-R®

Main Highlights

1. Reduced Insulation Thickness Requirements
2. Outstanding Compressive Strength Performance
3. Suitable for Underfloor Heating Systems
4. Reinforced Edge Strips for Precise Installation
5. Superior U-values via Lower Lambda Values

Key Highlights

1. BBA Certified product.
2. Compressive strength exceeding 150 (kPa).
3. High-performance rigid phenolic insulation solution.
4. Euroclass D -s1, d0 fire classification rating.
5. Fully compatible with Underfloor Heating (UFH) systems.
6. Perfect for new builds, retrofits, and renovation projects.
7. Excellent thermal conductivity at 0.021 W/mK.
8. Minimises thermal bridging issues.
9. Reduces condensation formation risk.
10. Simple installation thanks to lightweight construction.
11. Integrated vapour control layer included.
12. Thinner insulation layer needed.
13. Standard board size of 2400mm x 1200mm (8 x 4).
14. Perimeter strips for enhanced detailing.
15. Better U-values through reduced lambda ratings.
16. Handling, Cutting, and Storage Guidelines:
17. Store Unilin insulation on a clean, raised platform in a sheltered location away from weather.
18. Polythene wrapping alone does not provide adequate outdoor protection.
19. Take precautions during storage and construction to protect the insulation.
20. Always use appropriate Personal Protective Equipment (PPE) when handling insulation.
21. 60mm phenolic floor insulation board

Handling, Cutting, and Storage

Unilin Phenolic Insulation Board must be stored on a raised, clean, level surface in a sheltered environment protected from weather exposure. Polythene wrapping alone cannot provide sufficient protection from outdoor conditions. Take appropriate precautions to protect the insulation during both storage and building work. Wear suitable personal protective equipment (PPE) at all times when handling insulation materials.

Info

Explore our full Unilin range and use the left-hand filters to narrow down by thickness or coverage area. For advice on product suitability for your specific project or to request a bulk discount quotation, contact us on +4402038839057 , email sales@insulationbee or use Live Chat - Competitive UK Insulation board Pricing.
