Unilin Safe-R SR/UF 40mm Phenolic Floor Insulation

40mm Unilin Safe-R SR/UF Phenolic Floor Insulation Board delivers premium rigid phenolic insulation with outstanding fire performance characteristics. Featuring dual aluminium facings with low emissivity properties, this board achieves an exceptional thermal conductivity of just 0.020 W/mK, enabling superior U-Values in flooring insulation systems.

Uninsulated floors allow significant heat to escape downwards, compromising energy efficiency. The 40mm Unilin SR/UF Phenolic Floor Insulation Board transforms both new and existing floors by delivering improved U-values and thermal performance. This solution combines lightweight handling with straightforward installation, robust compressive strength, and minimal thermal conductivity—creating an exceptionally efficient flooring insulation product.

Product Details

Brand: Unilin®

Model: 40mm SR/UF

Thickness: 40mm

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 40mm

Pack Coverage: 20.16m2

Board Coverage: 2.88m2

Pack Weight: 30kg

Pack Quantity: 7 Sheets

Compressive Strength: >150 (kPa)

Material: Phenolic resins

Profile: Square Edge

R-Value: 1.56m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass D -s1, d0

Building Regulations: Compatible

Finish: Aluminium foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Floors ǀ Underfloor Heating Insulation

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes

Features: Underfloor Heating Insulation Board

Manufacturer: Unilin Safe-R®

Main Highlights

1. Reduced Insulation Thickness Requirements
2. Outstanding Compressive Strength Performance
3. Suitable for Underfloor Heating Systems
4. Reinforced Perimeter Strips for Precise Installation
5. Optimised U-values via Lower Lambda Values

Key Highlights

1. Holds BBA Certification.
2. Delivers Compressive Strength exceeding 150 (kPa).
3. Premium performance with rigid phenolic insulation.
4. Achieves Euroclass D -s1, d0 fire classification.
5. Compatible with Underfloor Heating (UFH) systems.
6. Ideal for new construction, retrofitting, and renovation projects.
7. Excellent thermal conductivity at 0.021 W/mK.
8. Minimises thermal bridging issues.
9. Reduces condensation risk significantly.
10. Simple installation thanks to lightweight construction.
11. Integrated vapour control layer included.
12. Thinner insulation layer needed.
13. Standard board size of 2400mm x 1200mm (8 x 4).
14. Reinforced detailing with perimeter strips.
15. Enhanced U-values through optimised lambda values.
16. Handling, Cutting, and Storage Guidelines:
17. Store Unilin insulation on a clean, raised surface in a sheltered location away from weather exposure.
18. Polythene wrapping alone does not provide adequate outdoor protection.
19. Protect the insulation carefully during storage and construction work.
20. Always use appropriate Personal Protective Equipment (PPE) when handling insulation.
21. 40mm phenolic floor insulation board

Handling, Cutting, and Storage

Unilin Phenolic Insulation Board must be stored on an elevated, clean, level surface and kept sheltered from weather conditions. Polythene wrapping alone cannot protect against outdoor elements. Take appropriate precautions to protect the insulation during both storage and construction phases. Wear suitable personal protective equipment (PPE) when handling insulation materials.
