50mm Unilin Safe-R SR/UF Phenolic Floor Insulation Board

50mm Unilin Safe-R SR/UF Phenolic Floor Insulation Board delivers premium rigid phenolic insulation with outstanding fire performance. Featuring dual aluminium facings with low emissivity properties, this board achieves an impressive thermal conductivity of just 0.020 W/mK, enabling superior U-Values in flooring insulation systems.

Floors lose considerable heat downward without adequate insulation protection. The 50mm Unilin SR/UF Phenolic Floor Insulation Board transforms both new and existing floors by dramatically improving thermal performance. Beyond thermal efficiency, this solution offers lightweight handling, straightforward fitting, and combines robust compressive strength with minimal heat loss—delivering outstanding insulation performance for any flooring application.

Product Details

Brand: Unilin®

Model: 50mm SR/UF

Thickness: 50mm

Length: 2400mm

Width: 1200mm

Dimensions: 2,400mm x 1,200mm x 50mm

Pack Coverage: 17.28m2

Board Coverage: 2.88m2

Pack Weight: 30kg

Pack Quantity: 6 Sheets

Compressive Strength: >150 (kPa)

Material: Phenolic resins

Profile: Square Edge

R-Value: 2.35 m2K/W

Thermal Conductivity: 0.021W/mK

Fire Classification: Euroclass D -s1, d0

Building Regulations: Compatible

Finish: Aluminium foil facings

Inner facing: Foil facing

Outer facing: Foil facing

Shipping method: Articulated Vehicle ǀ Courier

Applications: Floors ǀ Underfloor Heating Insulation

BBA Certified: Yes (no. 10/4803)

Vapour Control Layer: Yes

Features: Underfloor Heating Insulation Board

Manufacturer: Unilin Safe-R®

Main Highlights

1. Reduced Insulation Thickness Requirements
2. Excellent Compressive Strength Performance
3. Suitable for Underfloor Heating Systems
4. Reinforced Perimeter Strips for Enhanced Detailing
5. Superior U-values via Lower Lambda Ratings

Key Highlights

1. Holds BBA Certification.
2. Delivers Compressive Strength exceeding 150 (kPa).
3. Premium rigid phenolic insulation performance.
4. Achieves Euroclass D -s1, d0 fire classification.
5. Works seamlessly with Underfloor Heating (UFH).
6. Perfect for new construction, retrofitting, and renovation projects.
7. Excellent thermal conductivity at 0.021 W/mK.
8. Minimises thermal bridging issues.
9. Reduces condensation risk.
10. Simple installation thanks to lightweight design.
11. Integrated vapour control layer included.
12. Thinner insulation layer needed.
13. Standard board size of 2400mm x 1200mm (8 x 4).
14. Strengthened perimeter strips for better detailing.
15. Enhanced U-values through reduced lambda values.
16. Handling, Cutting, and Storage Guidelines:
17. Store Unilin insulation on a clean, raised platform and protect from weather exposure.
18. Polythene wrapping alone does not provide adequate outdoor protection.
19. Take precautions during storage and construction to protect the insulation.
20. Always use appropriate Personal Protective Equipment (PPE) when handling insulation.
21. 50mm phenolic floor insulation board

Handling, Cutting, and Storage

Unilin Phenolic Insulation Board must be stored on a raised, clean, level surface and kept protected from weather conditions. Polythene wrapping alone cannot provide sufficient protection from outdoor elements. Take appropriate steps to protect the insulation during storage and throughout the building phase. Wear suitable personal protective equipment (PPE) at all times when handling insulation.
