Cordek Filcor 20 EPS Structural Fill Insulation

Filcor 20 EPS - A lightweight Expanded Polystyrene structural fill solution, increasingly selected for its efficiency and versatility across numerous construction applications as a modern alternative to traditional filling methods.

Made to order sizes ( Request a quote with your requirements and we will get back to you asap )

The flexibility of Filcor 20 allows custom manufacturing of virtually any shape, size or profile with quick turnaround. Multiple material grades with varying compressive strengths are available to suit your specific loading needs whilst delivering excellent value. Availability :

1. Thickness (25 - 1200mm)
2. Length/Slab (max 2400mm)
3. Width/Slab (max 1200mm)
4. Grades: 20 , 45, 70, 90, 100, 120, 140, 160, 190
5. Lead times: 3-5 working days

Product Details

Brand: Cordek®

Model: Filcor EPS

Thickness: from 25mm up to 1200mm

Standard Length: 2400mm

Standard Width: 1200mm

Coverage: 2.88m2

Dimensions: 2,400mm x 1,200mm x ( Thickness made to order )

Custom : max concrete depth 800 - 7600mm

Compressive Strength: from 20 up to 190 (kPa)

Density: from 15 up to 55 (kg/m3)

Material: EPS (Expanded Polystyrene)

Profile: Square Edge (SE)

Thermal Conductivity: from 0.038 up to 0.033 (W/mK)

Fire Classification: Euroclass E

Vapour Resistivity: Water resistant

Shipping method: Rigid Vehicle ǀ Courier

Applications: Structural fill material

Features: Versatile ǀ Cost effective solution

Characteristics:

1. Multiple compressive strength grades to suit different requirements
2. Lightweight and easy to handle on site
3. Supplied in standard sheets or custom blocks
4. Bespoke profiling available to match your exact specifications
5. Delivers outstanding insulation performance
6. Includes flame retardant (FR) technology

Applications

Filcor 20 EPS insulation serves a broad spectrum of uses, from lightweight structural fill to thermal insulation. Choose from standard sheet dimensions or request custom sizing to match your installation requirements precisely. Standard sheets/blocks are 2400mm long and 1200mm wide, with depth tailored to your needs. Each Filcor sheet/block can be manufactured to your preferred depth, from a minimum of 25mm to a maximum of 1200mm. Cordek also provides the option to hire an individual Hot Wire Cutter for specialised cutting.

1. Hard Landscaping - Available in multiple compressive strengths to handle different loads, from light foot traffic to heavy vehicle weights.
2. Soft Landscaping - Can be profiled to form landscape features and intricate shapes
3. Podium Slab - Ideal for both hard and soft landscaping applications
4. Swimming Pools - Lightweight void former profiled to create accurate pool floor gradients with precision.
5. Steps, ramps and shapes - Pre-fabricated off-site with Filcor cut and profiled before delivery, including bespoke complex geometries.

Environmental facts about Filcor EPS

The production of Filcor insulation demonstrates exceptional environmental responsibility. Steam plays a crucial role in the process, being recycled repeatedly throughout manufacturing. The production method generates zero waste, with all offcuts and rejected material being reclaimed and reused.

Resource-Efficient Composition: Filcor comprises 98% air, making it an exceptionally resource-efficient material with a remarkably low carbon footprint.

Eco-Friendly Attributes: Cordek Filcor is manufactured without HFC, CFC, or HCFC. Its blowing agent, Pentane, has an exceptionally low Global Warming Potential (GWP) rating below five. Pentane is not classified as hazardous to human health or the environment under EU regulations.

Styrene Origins and Natural Occurrence: Styrene, used in Filcor manufacturing, occurs naturally in many everyday products including strawberries, beans, nuts, beer, wine, coffee beans, and cinnamon.
