155mm Heaveguard Pile Collars EPS

155mm Heaveguard Pile Collars EPS are lightweight, compressible products made from low-density Expanded Polystyrene. They are utilised to protect foundations from ground heave. These collars form a key part of the Cordek Cellcore ground heave system, making installation straightforward by wrapping securely around the pile. They also provide a square edge for neat fitting of Cellcore panels. 155mm Heaveguard Pile Collars are made from green-coloured low-density expanded polystyrene, making them simple to spot on site. They're supplied in a range of collar sizes and thicknesses to suit different project needs.

Product specification

Brand: Cordek®

Model: 155mm Pile Collars

Thickness: 155mm

Standard Length: 450mm

Standard Width: 450mm

Standard Dimensions: 450mm x 450mm x 155mm

Available Dimensions: 450mm x 600mm / 500mm x 500mm / 600mm x 600mm / 600mm x 800mm / 700mm x 700mm / 800mm x 800mm / 900mm x 1200mm / 1200mm x 1200mm

Colour: Light green or pink

Material: Expanded Polystyrene (EPS Insulation)

Profile: Compressible-fill material

Shipping method: Rigid Vehicle ǀ Courier

Grade: Meets the NHBC's Technical Standards

Applications: Foundations ǀ Piled Ground Beams

BBA Certified: Yes (No.17/5448)

Soil heave potential: Medium

Features: Protection Against Ground Heave ǀ Foundations

Safe load: 20 kN/m2

Fail load: 40 kN/m2 produce 50% compression

Manufacturer: Cordek®

Key Benefits:

1. Streamlines installation of Cellcore panels with ease
2. Delivers dependable protection from ground heave
3. Offered in multiple collar sizes and thicknesses for various applications
4. Green colour allows quick identification during construction

Availability

Each 155mm Heaveguard Pile Collar is typically made to match the width of your ground beam and the thickness of your chosen Cellcore panel. The inner void is precisely sized to fit your pile's diameter. Each pile collar comes in two parts for convenient installation.

Available Sizes: Standard pile collar thickness options*: 85mm, 155mm, and 220mm.

To request a quotation, please supply the following details: Required Quantity Required Length/Slab (Standard 450mm / Max 1200mm) Required Width/Slab (Standard 450mm / Max 1200mm)

Additional thicknesses and plan sizes are obtainable on request. For further details, contact the InsulationBee Technical Team on 02038839057.
