130mm Cellcore HX Plus Concrete Floor Slab Insulation

130mm Cellcore HX Plus Concrete Floor Slab Insulation combines ground heave protection with thermal performance when installed beneath reinforced concrete floors. This advanced product features a cellular Expanded Polystyrene core bonded to a Filcor insulation layer and covered with a protective polypropylene sheet. Each board is precision-engineered and tested to deliver consistent, reliable performance.

Product specification

Brand: Cordek®

Model: 130mm Cellcore HX Plus

Thickness: 130mm

Length: 2400mm

Width: 1200mm

Board coverage: 2.88m2

Available Grades: 7/10, 9/13, 13/18, 18/24, 24/32

Dimensions: 2,400mm x 1,200mm x 130mm

Beams Widths: 2400mm x 1200mm to 300mm (in 25mm increments)

Material: EPS Insulation ǀ Filcor ǀ Polypropylene

Shipping method: Rigid Vehicle ǀ Courier

Applications: Reinforced concrete floor slabs

BBA Certified: Yes (no.11/4862)

Maximum depth of concrete: 220mm

Features: Insulated Heave Protection Board

Safe load: 7 kN/m2

Shrinkage Category: Low

Manufacturer: Cordek Cellcore HX PLUS®

Made to order sizes ( Request a quote with your requirements and we will get back to you asap )

The flexibility of 130mm Cellcore HX Plus allows for custom manufacturing of virtually any shape, size or profile with competitive lead times. A selection of materials with varying compressive strengths is available to match your application's load requirements whilst delivering excellent value.

To request a quotation, please supply the following details:

1. Required Quantity
2. Required Thickness (130 - 365mm)
3. Required Length/Slab (Standard 2400mm)
4. Required Width/Slab (Standard 1200mm)
5. Required Grade: 7/10, 9/13, 13/18, 18/24, 24/32

Usability

Key Attributes:

1. Resists upward pressure from ground heave affecting your building.
2. Integrated Filcor insulation matched to your U-value requirements.
3. Wide range of profiles and grades for different applications.
4. BBA certified for quality and performance.
5. Meets NHBC Technical Standards.
6. Precision-moulded construction for superior, uniform results.
7. 130mm HX Plus underfloor / underground insulation board

The standard product range comes in multiple depths and grades to suit typical combinations of soil heave risk, concrete thickness and U-value specifications.

Usage Scenarios:

130mm Cellcore HX Plus is designed for installation beneath reinforced concrete floor slabs, providing insulated ground heave protection.

Suitability:

To establish the right product specification, first select the appropriate 130mm Cellcore HX depth and grade to counteract ground heave whilst supporting structural loads. Then calculate the necessary Filcor insulation thickness to achieve your target U-value.

Thickness (mm) / Thermal Resistance m2c/w

1. 50mm (Standard) / 1.39m2c/w
2. 75mm / 2.08m2c/w
3. 100mm / 2.78m2c/w
4. 125mm / 3.47m2c/w
5. 150mm / 4.17m2c/w
