110mm Unilin Thin-R XT/UF PIR Floor Board

The 110mm Unilin Thin-R XT/UF PIR Floor Insulation Board is a high-performance rigid PIR insulation solution engineered for floor construction applications. This product delivers thermal and structural performance comparable to premium brands such as Kingspan TF70 whilst offering superior value for money.

Featuring a thermal conductivity of 0.022W/mK and compressive strength exceeding 150kPa, this 110mm floor insulation board maintains structural stability under load whilst delivering outstanding thermal performance. It represents an efficient and economical solution for floor insulation requirements.

Product Details

Brand: Unilin XT/UF

Thickness: 110mm

Length: 2400mm

Width: 1200mm

Available Thicknesses: 15mm, 20mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 60mm, 65mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 130mm, 140mm, 150mm, 160mm, 165mm

Maximum Board Weight: 0.45 kg/m²

Thermal Resistance: 0.68m²K/W

Thermal Conductivity: 0.022 W/mK

Compressive Strength: >150 kPa

Water Vapour Resistivity: >100 MNs/gm

Density (Foam Core): 30-32 kg/m³

Surface Spread of Flame: Class 1

Reaction to Fire: E

Finish: Aluminium Foil Facings

Applications: Ground Supported & Suspended Floors

ETA Notification: Yes

Features: Versatile ǀ High-performance ǀ Rigid

Key Points

1. Excellent compressive strength for load-bearing applications
2. Compatible with underfloor heating systems
3. Perimeter strips available for precise detailing
4. Achieves superior thermal performance with reduced thickness
5. Low emissivity foil facings enhance thermal efficiency

About

Floors with inadequate insulation contribute to significant heat loss in buildings. The 110mm XT/UF Thin-R Underfloor Insulation effectively addresses this challenge by substantially improving the U-Value of both new construction and retrofit applications.

This Unilin XT/UF product combines lightweight construction with straightforward installation. The combination of high compressive strength and low thermal conductivity ensures optimal performance for demanding floor insulation board applications.
