45mm Unilin Thin-R XT/UF PIR Floor Insulation Board

The 45mm Unilin Thin-R XT/UF PIR Floor Insulation Board is a premium rigid PIR insulation solution engineered for floor construction applications. Contractors and installers favour this product for delivering thermal performance comparable to leading brands such as Kingspan TF70 whilst offering superior value for money.

Featuring a thermal conductivity of 0.022W/mK and compressive strength exceeding 150kPa, this 45mm floor insulation board provides outstanding thermal performance with excellent load-bearing capacity. It represents a reliable and economical solution for achieving effective floor insulation across residential and commercial projects.

Product Details

Brand: Unilin Thin-R XT/UF

Thickness: 45mm

Length: 2400mm

Width: 1200mm

Overall Thickness: 15mm, 20mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 60mm, 65mm, 70mm, 75mm, 80mm, 90mm, 100mm, 110mm, 120mm, 130mm, 140mm, 150mm, 160mm, 165mm

Maximum Board Weight: 0.45 kg/m²

Thermal Resistance: 0.68m²K/W

Thermal Conductivity: 0.022 W/mK

Compressive Strength: >150 kPa

Water Vapour Resistivity: >100 MNs/gm

Density (Foam Core): 30-32 kg/m³

Surface Spread of Flame: Class 1

Reaction to Fire: E

Finish: Aluminium Foil Facings

Applications: Ground Supported & Suspended Floors

ETA Notification: Yes

Features: Versatile ǀ High-performance ǀ Rigid

Key Points

1. Excellent compressive strength for load-bearing applications
2. Compatible with underfloor heating systems
3. Perimeter strips enable precise detailing and edge protection
4. Minimised insulation thickness without compromising performance
5. Low emissivity aluminium foil facings

About

Floors that lack adequate thermal insulation result in significant heat loss within buildings. The 45mm XT/UF Thin-R Underfloor Insulation effectively resolves this concern by substantially improving the U-Value performance of both newly constructed and refurbished floors.

Unilin XT/UF combines lightweight construction with straightforward installation characteristics. The product delivers an exceptional balance of high compressive strength and low thermal conductivity, establishing it as the preferred choice for superior floor insulation board performance and durability.
