40mm Unilin XT/CW Partial Fill Cavity Insulation

The 40mm Unilin XT/CW Partial Fill Cavity Wall (T&G) system incorporates engineered tongue and grooved joints with pre-formed corner elements. This construction delivers continuous insulation coverage and reduces thermal bridging effectively.

Engineered for traditional masonry walls, this 40mm cavity wall product meets rigorous thermal performance requirements. It delivers superior thermal efficiency whilst maintaining a residual cavity space, offering robust defence against wind-driven rain penetration.

This XT/CW system is available in both Square Edge and Tongue and Grooved configurations. The 40mm Unilin XT/CW was previously marketed as 40mm Xtratherm XT/CW.

Product Specification

Brand: Unilin / Xtratherm®

Thickness: 40mm

Model: 40mm XT/CW Cavity Wall Insulation Tongue & Groove

Weight: 5.83 kg

Dimensions: 1,200mm x 450mm x 40mm

Density: 30Kg/m3

Length: 1200mm

Width: 450mm

Board Coverage: 0.54 m²

Pack Coverage: 4.86 m²

Material: Polyisocyanurate (PIR)

Profile: Square Edge

R-Value: 1.82 m2K/W

Thermal Conductivity: 0.022 W/mk

Vapour Resistivity: 100 MNs/gm

Surface Spread of Flame: Class 1

Compressive Strength: >120kPa

Applications: Cavities ǀ Masonry Walls

Inner facing: Foil facing

Outer facing: Foil facing

BBA Certified: Yes (No. 08/4613)

Features: Lightweight ǀ Easy to handle and install

Important Features From Our 40mm XT/CW Partial Fill:

1. Robust and reliable tongue and groove joint system.
2. Integrated corner panels and cavity closers reduce thermal bridging.
3. Preserves a clear cavity for optimal thermal performance.
4. Unrestricted exposure capability.
5. Fitted with low emissivity foil facings to enhance Cavity insulation performance.
