100mm Kingspan Kooltherm K5 External Wall Insulation Board

100mm Kingspan Kooltherm K5 External Wall Insulation Board delivers premium thermal performance for masonry wall applications. Built with a fibre-free, rigid thermoset phenolic core, this solution excels in external wall insulation systems and thin coat rendering applications.

The 100mm K5 board works seamlessly with both traditional and lightweight polymer-modified renders. Installation occurs entirely from the outside, allowing you to upgrade existing properties without internal disruption.

As one of the market's thinnest external wall insulation board (EWI) options, it maximises internal space—essential for buildings where internal insulation proves impractical.

Mineral glass facings are bonded to the insulation core during manufacturing, delivering a certified thermal conductivity (lambda) of 0.022 W/mK. The phenolic core achieves exceptional thermal efficiency using a blowing agent with zero Ozone Depletion Potential (ODP) and low Global Warming Potential (GWP).

This 100mm board satisfies Building Regulations with outstanding thermal performance in a reduced thickness. It delivers superior insulation values with a thinner profile than EPS, XPS, and mineral wool alternatives.

Each board measures 1200mm x 600mm x 100mm, ensuring lightweight handling and straightforward installation.

Product specification

• Brand: Kingspan
• Model: 100mm K5 Single Board
• Thickness: 100mm
• Length: 1200mm
• Width: 600mm
• Weight: 0.57kg
• Dimensions: 1,200mm x 600mm x 100mm
• Board Coverage: 0.72m2 per board
• Pack Coverage: 0.72m2
• Pack Quantity: 1 board
• Compressive Strength: 100kPa
• Density: 35kg/m3
• Thermal Conductivity: 0.022 W/mK
• R-Value: 2.50m2K/W
• Material: Rigid thermoset phenolic insulation
• Profile: Square edge
• Colour: Light shade of red
• Fire Classification: Euroclass C-s2,d0
• Finish: Mineral glass coatings
• Application Temperature: from +5 °C to +25 °C
• Applications: External insulation for masonry walls
• BBA Certified: Yes
• Features: Thinnest commonly used External Wall Insulation Board
• Manufacturer: Kingspan Kooltherm® K5

Application

Installation of Kooltherm K5 boards requires adherence to the manufacturer's comprehensive guidelines, which outline detailed design and application procedures. For best performance, secure boards to your substrate (masonry or timber) using Premium Basecoat combined with metal screw mechanical fixings.

After fixing boards to the external wall, apply a protective outer layer. Choose between a mortar basecoat or netting cover to guard against excessive heat, moisture, and UV damage. Complete the system with a protective render topcoat. Consult our full installation guide for comprehensive instructions.

Storage Instructions

Shelf Life: Refer to the manufacturer's expiry date. Storage Conditions: Store in a dry location, in the original packaging, and away from excessive heat or UV light.

Applications

• · External wall insulation systems:
• · Solid brick and block walls.
• · Cavity block and brick walls.
• · Thin coat rendering.
• · Cavity brick walls.
• · Cavity dense block walls.
• · Insulated render systems.
• · Steel-framed walls
• · Timber-framed walls.

Kingspan Kooltherm K5 Installation

We recommend

1. Adhesive and Base-Coat Render: EWI-225 Premium Basecoat Render Adhesive 25kg,
2. Rendering Mesh: Orange Fibreglass Rendering Mesh Roll,
3. Priming Paint: EWI-333 Top Coat Primer,
4. Top Coat Thin Coat Render: EWI-075 Silicone Render.
5. Plastic Fixings: 140mm Insulation Panel Fixings Plastic Pin,
6. Metal Fixings: 140mm Insulation Panel Fixings LMX10 Metal Pin Hammer Fix,
7. Base Track: 100mm Aluminium Base Track | 2500mm length profile,
8. Render Beads and Profiles

What is Phenolic Insulation?

Kingspan K5 Phenolic insulation, including our Kooltherm range, ranks among the most thermally efficient insulation materials on the market. A specialised manufacturing process creates a rigid thermoset foam core sandwiched between two facing layers, such as low-emissivity composite foil.

Phenolic insulation enables you to achieve low target U-values with minimal insulation thickness, making it perfect for projects demanding high performance and space efficiency.
