90mm Unilin CavityTherm CT/PIR Full Fill Cavity Insulation

Introducing 90mm Unilin CavityTherm CT/PIR Full Fill Cavity Insulation, an engineered integrated thermal solution for conventional cavity walls, delivering passive-level U-Values as low as 0.12 W/m2K. This advanced system provides superior thermal bridging performance, even in cavities narrower than 90mm.

Product Details

Brand: Unilin

Model: 90mm CT/PIR Full Fill Insulation

Thickness: 90mm

Length: 1200mm

Width: 450mm

Size: 1200mm x 450mm

Pack Weight: 4.90kg

Pack Coverage: 2.16m2

Dimensions: 1,200mm x 450mm x 90mm

Density: 30Kg/m3

Compressive Strength: 100kPa

Material: Polyisocyanurate (PIR insulation Board)

Profile: Unique engineered profiled facing

Inner facing: Foil facing

Outer facing: HIP facer

R-Value: 4.07m2K/W

Thermal Conductivity: 0.021 W/mk

Vapour Resistivity: 100 MNs/gm

Applications: Cavities ǀ External Walls

BBA Certified: Yes (No. 10/4786)

Features: Excellent U-Values ǀ Passive House

Key Highlights:

1. The engineered HIPS facer offers effective protection against wind-driven rain.
2. Moisture is efficiently redirected towards the exterior surface.
3. Precisely positioned slots accommodate sloping wall ties, eliminating any potential creep.
4. The system boasts fully engineered jointing, removing the need for reliance on taping.
5. Impressive Thermal Bridging Values contribute to enhanced insulation performance.
6. 90mm Full Fill Insulation Board

About

The 90mm CavityTherm CT/PIR wall insulation board is a high-performance composite panel with an enhanced PIR core delivering a thermal conductivity of 0.021W/mK. These boards feature gas-tight facings with a profiled HIPS skin bonded during manufacturing to create an effective drainage plane. The engineered profiled facing of 90mm CavityTherm directs any potential moisture infiltration from the external wall downwards along the protective facing, channelling it onto the external leaf. This design provides robust protection against wind-driven rain exposure.

Furthermore, the 90mm Unilin Full Fill Insulation Board incorporates specially engineered rebated edge details on all four sides, creating a tight interlocking system during installation. This precision-engineered interlock ensures continuous insulation coverage with exceptional thermal bridging performance.

When installed in a conventional 100-150mm cavity using standard construction methods and materials, 90mm CavityTherm achieves U-values as low as 0.12W/m2K. This represents a practical and economical approach to low-energy design objectives, whilst preserving the aesthetic character of traditional properties.

Real performance on site

90mm Unilin CT/PIR features specially engineered profiled facing that effectively channels any potential moisture infiltrating the external wall insulation downwards along the protective surface. This design redirects moisture back onto the external leaf, delivering enhanced protection against wind-driven rain, particularly important in today's climate conditions.
