Recticel Eurothane GP 80mm PIR Insulation Board

80mm Recticel Insulation Eurothane® GP is a high-performance PIR insulation board engineered for straightforward cutting, handling, and fitting. This adaptable product suits multiple building applications, including pitched roofs, timber-framed walls, and floor systems. Professionals specify 80mm Eurothane GP for its superior thermal efficiency, delivering a thermal conductivity of λ = 0.022 W/mK, alongside rapid, trouble-free installation.

Properties

Brand: Recticel®

Model: 80mm Eurothane GP

Thickness: 80 mm

Dimensions: 2,400mm x 1,200mm x 80 mm

Length: 2400mm

Width: 1200mm

Density: 30kg/m3

Weight: 6.91kg

R-Value: 3.60 m2K/W

Thermal Conductivity: 0.022 W/mk

Material: Polyisocyanurate | PIR Insulation

Compressive Strength: 25-49mm: 120 kPa | 50-160mm: 140 kPa

Vapour Resistivity: 100 MNs/gm

Finish: Gas diffusion tight multilayer foil on both sides and grid on both sides.

Edge finishing: Square edges

Fire performance: Euroclass F

Applications: Thermal insulation of Pitched roofs, Framed walls, Floors (compatible with underfloor heating systems).

Features: Reduce the heating and cooling costs

Model: 80 mm Eurothane GP

How to insulate Pitched Roofs with Eurothane® GP?

Specialists favour 80mm Eurothane® GP boards for their lightweight construction, straightforward fitting, and on-site cuttability. Position boards with long edges parallel to rafters, pressing them together tightly in a brick-bond arrangement. Support board joints that run from eaves to ridge using rafters. Temporary nail fixings can be applied before counter battening.

How to insulate Framed Walls with Eurothane® GP?

Install 80mm PIR boards between wall battens in a tightly butted brick-bond configuration.

How to insulate floors with Eurothane® GP?

Lay Eurothane boards in a tightly butted brick-bond pattern. Where two layers are needed for desired thickness, stagger the board joints and position the thicker layer externally.

Recticel PIR The Advantages

This 80mm Insulation meets rigorous manufacturing standards, streamlining installation significantly. Featuring precisely cut straight edges, uniform board dimensions, robust compressive strength, and a consistently flat surface, these boards enable faster, simpler, and more economical fitting. Choose Recticel PIR for dependable, high-quality construction results.

Floor Advantages

Selecting appropriate ground Floor Insulation demands attention to thermal and structural properties. Recticel 80mm PIR delivers excellent performance in residential and commercial applications, combining low thermal conductivity with high compressive strength across diverse floor constructions. Since underfloor heating features prominently in contemporary flooring, Recticel PIR's superior pipe clip retention makes it an ideal selection.

Recticel's PIR insulation extends beyond ground-level use. Eurothane FP suits soffit lining on intermediate floors above basements or car parks, combining outstanding thermal performance with Class 0 flame-spread certification.
