40mm Recticel Eurothane GP PIR Insulation Board

40mm Recticel Insulation Eurothane® GP is a high-performance PIR insulation board engineered for straightforward cutting, handling, and fitting. This adaptable product suits numerous applications including pitched roofs, timber-framed walls, and floor systems. Installers appreciate the 40mm Eurothane GP for its outstanding thermal efficiency, delivering a thermal conductivity of just λ = 0.022 W/mK, alongside straightforward on-site installation.

Properties

Brand: Recticel®

Model: 40mm Eurothane GP

Thickness: 40 mm

Dimensions: 2,400mm x 1,200mm x 40 mm

Length: 2400mm

Width: 1200mm

Density: 30kg/m3

Weight: 3.46kg

R-Value: 1.80 m2K/W

Thermal Conductivity: 0.022 W/mk

Material: Polyisocyanurate | PIR Insulation

Compressive Strength: 25-49mm: 120 kPa | 50-160mm: 140 kPa

Vapour Resistivity: 100 MNs/gm

Finish: Gas diffusion tight multilayer foil on both sides and grid on both sides.

Edge finishing: Square edges

Fire performance: Euroclass F

Applications: Thermal insulation of Pitched roofs, Framed walls, Floors (compatible with underfloor heating systems).

Features: Reduce the heating and cooling costs

Model: 40 mm Eurothane GP

How to insulate Pitched Roofs with Eurothane® GP?

Installers favour Eurothane® GP 40mm boards for their light weight, simple installation process, and ability to be cut to size on-site. Position boards with long edges running parallel to rafters, then push them tightly together in a staggered brick-bond arrangement. Where board joints run from eaves to ridge, ensure they are supported by rafters. Temporary nailing can secure boards before counter battening is applied.

How to insulate Framed Walls with Eurothane® GP?

Install the 40mm PIR boards in a tight brick-bond pattern between the timber wall frame members.

How to insulate floors with Eurothane® GP?

Lay Eurothane boards in a tightly butted brick-bond arrangement. When two layers are needed to reach target thickness, stagger the joints between layers and position the thicker layer facing outward.

Recticel PIR The Advantages

Our 40mm Insulation meets exacting manufacturing standards, streamlining the installation process. Featuring precisely cut edges, uniform board dimensions, robust compressive strength, and a level surface finish, these boards enable faster, simpler, and more economical installation. Select Recticel PIR for dependable, high-quality results.

Floor Advantages

Choosing appropriate ground Floor Insulation involves balancing thermal and structural performance. Recticel 40mm PIR delivers excellent results for residential and commercial projects, combining low thermal conductivity with high compressive strength across different floor designs. Since underfloor heating is increasingly common in contemporary buildings, Recticel PIR's superior pipe clip retention makes it an ideal solution.

Recticel's PIR insulation extends beyond ground-level applications. Eurothane FP works well for soffit lining on intermediate floors above basements or car parks, delivering matching thermal performance alongside a Class 0 spread of flame classification.
