Unilin Thin-R XT/TF 30mm Timber Frame Wall Insulation

Timber Frame construction employs substantial timber members to establish the primary building framework. In timber frame buildings, the external structural wall incorporates timber studs that transfer structural loads through to the foundation system. The walls, floors, and roofs function as an integrated, engineered structural assembly.

The 30mm Unilin Thin-R XT/TF system delivers enhanced thermal performance for timber framed wall insulation, exceeding current building regulation baseline requirements. This 30mm board for timber framed walls facilitates achievement of Future Home and Passive House Standards.

Product Specification

Brand: Unilin

Thickness: 30mm

Available Thicknesses: 25mm, 30mm, 40mm, 50mm, 60mm, 80mm, 100mm, 120mm

Dimensions: 2.4m x 1.2m x 30mm

Area: 2.88m²

Density: 30kg/m³

Thermal Conductivity: 0.022W/mK

Thermal Resistance: 1.50 m²K/W

Compressive Strength: 140kPa

Water Vapour Resistivity: 100MN.s/g.m

Surface Spread of Flame: Class 1

Type: PIR Insulation for timber frame walls

Application: Wall Insulation

Inner Facing: Foil Facer

Outer Facing: Foil Facer

Compressive Strength Rating: CS (10\Y) 140

Reaction to Fire: Euroclass E

EPD: An Environmental Product Declaration (EPD), certified by IGBC, is available for this product.

Key Features of 30mm Unilin XT/TF

1. Fast-track assembly system
2. Compatible with fibre stud applications
3. Suitable for new build and retrofit projects
4. Compact board thickness
5. Low emissivity foil facing technology
